| 1. |
85802820
|
[1] |
CHECK VALVE
|
IMO
Load Check
|
| 2. |
76350
|
[2] |
HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC
|
NH
Incl 25
|
| 3. |
163335
|
[2] |
TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BEL
Incl 25
|
| 4. |
84419297
|
[2] |
HYDRAULIC HOSE,9.53mm ID x 3048mm L, SAE 100R17
|
PLO
3048mm
|
| 5. |
9801618
|
[2] |
QUICK MALE COUPLING,1/2" - 14
|
NH
Male Coupling Superseded by part number: 9412
|
| 6. |
87017808
|
[2] |
DUST CAP
|
RAC
Blue
|
| 7. |
86624468
|
[1] |
SPACER,1.65" L x 5/16” Thk
|
NH
Switch
|
| 8. |
86642946
|
[1] |
BAR
|
NH
|
| 9. |
86594422
|
[1] |
SENSOR
|
NH
Rotor Knife
|
| 10. |
84422400
|
[1] |
HYDRAULIC HOSE,9.53mm ID x 1850mm L, SAE 100R17
|
PLO
|
| 11. |
76344
|
[2] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
|
NH
Incl 25
|
| 12. |
330346
|
[2] |
45 ELBOW,45 Degree, 9/16"-18, 37 Degree x 9/16"-18, O-Ring
|
NH
Incl 25
|
| 13. |
84422404
|
[1] |
SUPPORT
|
PLO
|
| 14. |
86900322
|
[2] |
SCREW,Phillips Drive, Truss HD, #10 - 24 x 1-1/4", SST
|
PA
|
| 15. |
86511481
|
[2] |
FLANGE BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8
|
NH
|
| 16. |
86511315
|
[2] |
WASHER,8.4mm ID x 16mm OD x 1.8mm Thk
|
NH
Superseded by part number: 86624184
|
| 17. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 18. |
86900323
|
[2] |
NUT,#10 - 24
|
PA
|
| 19. |
261066
|
[2] |
ORIFICE,9/16" - 18, 0.813" Orifice
|
NH
|
| 20. |
620019
|
[2] |
CLAMP
|
NH
Hose
|
| 21. |
86566989
|
[12] |
CABLE TIE,208mm L
|
ZED
|
| 22. |
9804258
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 23. |
9804277
|
[2] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 24. |
86000441
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 25. |
9617873
|
[8] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
NH
|
| 26. |
87024765
|
[2] |
CLAMP,36.5mm, Coat, 10.3mm Bolt Hole, P Type
|
ZED
|
