| 1. |
84422400
|
[2] |
HYDRAULIC HOSE,9.53mm ID x 1850mm L, SAE 100R17
|
PLO
|
| 2. |
128821
|
[2] |
UNION,9/16" - 18 JIC x 9/16" - 18 JIC
|
PA
|
| 3. |
84474326
|
[2] |
HYDRAULIC HOSE,9.53mm ID x 2800mm L, SAE 100R17
|
PLO
|
| 4. |
9801618
|
[2] |
QUICK MALE COUPLING,1/2" - 14
|
NH
Superseded by part number: 9412
|
| 5. |
87017807
|
[2] |
DUST CAP
|
PA
Red Superseded by part number: 333721A1
|
| 6. |
263117
|
[3] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
|
| 7. |
85802820
|
[1] |
CHECK VALVE
|
IMO
Load
|
| 8. |
86624468
|
[1] |
SPACER,1.65" L x 5/16” Thk
|
NH
|
| 9. |
86642946
|
[1] |
BAR
|
NH
|
| 10. |
86594422
|
[1] |
SENSOR
|
NH
Rotor Knife
|
| 11. |
86900322
|
[2] |
SCREW,Phillips Drive, Truss HD, #10 - 24 x 1-1/4", SST
|
PA
|
| 12. |
86900323
|
[2] |
NUT,#10 - 24
|
PA
|
| 13. |
330346
|
[5] |
45 ELBOW,45 Degree, 9/16"-18, 37 Degree x 9/16"-18, O-Ring
|
NH
Incl 25
|
| 14. |
9804276
|
[1] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 15. |
47484111
|
[2] |
HYDRAULIC HOSE,6.35mm ID x 610mm L
|
NH
|
| 16. |
76350
|
[1] |
HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC
|
NH
Incl 25
|
| 17. |
261066
|
[1] |
ORIFICE,9/16" - 18, 0.813" Orifice
|
NH
|
| 18. |
76344
|
[1] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
|
NH
Incl 25
|
| 19. |
86512445
|
[2] |
CARRIAGE BOLT,Sht Nk, M8 x 60mm, Cl 8.8
|
NH
|
| 20. |
600427
|
[2] |
CLAMP,25.4mm, Coat, 8.7mm Bolt Hole, P Type
|
NH
|
| 21. |
14496501
|
[8] |
WASHER,8.4mm ID x 17mm OD x 1.6mm Thk
|
TTF
Superseded by part number: 86624184
|
| 22. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 23. |
9824259
|
[2] |
WASHER,6.4mm ID x 12mm OD x 1.6mm Thk
|
NH
|
| 24. |
86977786
|
[1] |
BOLT,Hex, M6 x 1 x 25mm, Cl 8.8
|
GI
|
| 25. |
9617873
|
[6] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
NH
|
