凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (35.569.AB) - HYDRAULIC CYLINDER, DROP FLOOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
857 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87029395
|
[2] |
CYLINDER ASSY.,Double Acting, 19.05mm Rod, 119.89mm Stroke
|
PA
Drop Floor, Incl 2 - 13
|
| 2. |
514100
|
[1] |
OIL SEAL
|
NH
Wiper
|
| 3. |
514099
|
[1] |
WASHER,32.16mm ID x 38.16mm OD x 1.27mm Thk
|
NH
Back-Up, 1.266 ID x .043 Thk
|
| 4. |
87029766
|
[1] |
PISTON,1/2" ID x 1-1/2" OD x 1/2" Thk
|
PA
|
| 5. |
88130
|
[1] |
NUT,1/2"-20, GC
|
NH
|
| 6. |
87029765
|
[1] |
CYLINDER END CAP
|
PA
|
| 7. |
9826108
|
[1] |
SEAL,19.28mm ID x 25.2mm OD x 5.03mm Thk
|
NH
|
| 8. |
14463681
|
[1] |
O-RING,31.34mm ID x 3.53" Width
|
TTF
|
| 9. |
87030035
|
[1] |
PISTON ROD
|
PA
|
| 10. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Barrel, Incl in 1
|
| 11. |
86605608
|
[1] |
SEAL,31.34mm ID x 38.1mm OD x 4.75mm Thk
|
GI
Piston
|
| 12. |
87029768
|
[1] |
SEAL KIT
|
PA
Incl in 1
|
| 13. |
9992298
|
[1] |
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
|
BHB
|
