纽荷兰零件查询(CV900) - VIBRATORY ROLLER (9/01-) (03-002-00[01]) - ENGINE ACCELERATION New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
174 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | ND104303 | [1] | SUPPORT | STA |
| 3. | ND052690 | [1] | SUPPORT | STA |
| 4. | ND031144 | [1] | COVER | STA |
| 8. | ND050785 | [1] | LEVER | STA |
| 13. | ND050565 | [1] | PLATE | STA |
| 17. | ND021285 | [3] | BOLT | STAM5 x 12 |
| 19. | ND024381 | [4] | SCREW | STAM6 x 16 |
| 22. | ND021846 | [2] | NUT | STAM5 |
| 23. | ND027300 | [4] | NUT | STAM6 |
| 24. | ND054267 | [2] | SLEEVE | STA |
| 27. | ND029308 | [1] | WASHER | STAID 5,1 |
| 27A. | ND050648 | [1] | PIVOT | STA |
| 28. | ND029247 | [4] | WASHER | STAID 5,3 |
| 28A. | ND104359 | [1] | LEVER | STA |
| 29. | ND029248 | [4] | WASHER | STAID 6,4 |
| 31. | ND053025 | [1] | STOP | STA |
| 33. | ND050635 | [1] | SCREW | STA |
| 41. | ND023789 | [1] | SCREW | STAM5 x 8 Superseded by part number: ND110076 |
| 42. | ND021286 | [2] | BOLT | STAM6 x 10 |
| 61. | ND021847 | [2] | NUT | STAM6 |
| 62. | ND021848 | [3] | NUT | STAM8 Superseded by part number: ND034087 |
| 69. | ND029309 | [2] | SPRING WASHER | STAID 6,1 |
| 104. | ND076335 | [1] | CABLE SHEATH | STA3000mm |
| 105. | ND076337 | [1] | CABLE | STA3300mm |
