| 1. |
47462454
|
[1] |
WIRE HARNESS
|
NH
ISOBUS, Incl 17, Serial Range: -YFN188618 Superseded by part number: 47938509
|
| 1. |
47655927
|
[1] |
WIRE HARNESS
|
NH
ISOBUS, Incl 17, Serial Range: YFN188619-YGN190460
|
| 1. |
47938509
|
[1] |
WIRE HARNESS
|
NH
ISOBUS, Incl 17, Start Serial: YGN190461
|
| 2. |
47487624
|
[1] |
SUPPORT
|
NH
|
| 3. |
47385274
|
[1] |
MODULE
|
NH
ECU
|
| 4. |
84292754
|
[12] |
CLIP,Cable Tie W/ Fir Tree, 5mm OD x 203mm OAL
|
NH
|
| 5. |
86566989
|
[21] |
CABLE TIE,208mm L
|
ZED
|
| 6. |
87010656
|
[2] |
CLAMP,17.5mm, Coat, 10.3mm Bolt Hole, P Type
|
GI
|
| 7. |
43118
|
[1] |
BOLT,Hex, M6 x 1.0 x 40mm, Cl 8.8
|
NH
Superseded by part number: 120102
|
| 8. |
47565168
|
[1] |
SUPPORT
|
NH
, Serial Range: -YGN190282
|
| 8. |
47941032
|
[1] |
SUPPORT
|
NH
, Start Serial: YGN190283
|
| 9. |
86628564
|
[1] |
CLAMP,31.7mm, Coat, 10.3mm Bolt Hole, P Type
|
ZED
Superseded by part number: 515-23317
|
| 10. |
86507486
|
[1] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 11. |
9804277
|
[10] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 12. |
9804258
|
[6] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 13. |
47428546
|
[1] |
BRACKET
|
NH
|
| 14. |
619284
|
[3] |
CLAMP,23.8mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
Superseded by part number: 87029955
|
| 15. |
47398072
|
[1] |
MODULE
|
GI
|
| 16. |
9804255
|
[3] |
BOLT,Hex, M6 x 1 x 16mm, Full Thd, Cl 8.8
|
NH
|
| 17. |
82017871
|
[1] |
RELAY,12V, 20A
|
BAS
Superseded by part number: 84411012
|
| 18. |
86050300
|
[2] |
FLANGE NUT,M6 x 1.0, Cl 10
|
WIN
|
| 19. |
86610200
|
[2] |
THREADED INSERT,M8 x 1.25
|
NH
|
| 20. |
47585553
|
[1] |
DISPLAY
|
ZED
|
| 20. |
47585553R
|
[1] |
REMAN-ELECT MONITOR
|
RAC
Use Electronic Service Tool to Load Software.
|
| 20. |
47585553C
|
[1] |
CORE-MONITOR
|
RAC
Return Number
|
| 21. |
47520895
|
[1] |
WIRE HARNESS
|
NH
Cab, Serial Range: -YGN191557 Superseded by part number: 47938505
|
| 21. |
47938505
|
[1] |
WIRE HARNESS
|
NH
Cab, Start Serial: YGN191558
|
| 22. |
84558714
|
[3] |
SHOCK ABSORBER
|
GI
|
| 23. |
319725A1
|
[1] |
RUBBER WASHER
|
CAS
|
| 24. |
86619800
|
[1] |
FLANGE NUT,M6 x 1, Cl 8
|
RAC
|
| 25. |
47691332
|
[1] |
MOUNTING PLATE
|
NH
|
| 26. |
87742364
|
[4] |
SCREW,Pan Torx, M6 x 16mm, Cl 8.8
|
BRR
|
| 27. |
9804276
|
[7] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 28. |
86511839
|
[7] |
BOLT,Hvy Hex, M6 x 30mm, Cl 8.8
|
WIN
|
| 29. |
47538417
|
[1] |
WIRE HARNESS
|
NH
Battery, Start Serial: YGN191553
|
