| 1. |
47462454
|
[1] |
WIRE HARNESS
|
NH
ISOBUS, Incl 13 - 19, Serial Range: -YFN188618 Superseded by part number: 47938509
|
| 1. |
47655927
|
[1] |
WIRE HARNESS
|
NH
ISOBUS, Incl 13 - 19, Serial Range: YFN188619-YGN190460
|
| 1. |
47938509
|
[1] |
WIRE HARNESS
|
NH
ISOBUS, Incl 13 - 19, Start Serial: YGN190461
|
| 2. |
84292754
|
[5] |
CLIP,Cable Tie W/ Fir Tree, 5mm OD x 203mm OAL
|
NH
|
| 3. |
86566989
|
[9] |
CABLE TIE,208mm L
|
ZED
|
| 4. |
86628564
|
[3] |
CLAMP,31.7mm, Coat, 10.3mm Bolt Hole, P Type
|
ZED
Superseded by part number: 515-23317
|
| 5. |
9804277
|
[2] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 6. |
9804258
|
[3] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 7. |
86610200
|
[2] |
THREADED INSERT,M8 x 1.25
|
NH
|
| 8. |
47585461
|
[1] |
DISPLAY
|
ZED
Intel View III
|
| 8. |
47585461R
|
[1] |
REMAN-ELECT MONITOR
|
RAC
Intel View III
|
| 8. |
47585461C
|
[1] |
CORE-MONITOR
|
RAC
Return Number
|
| 8. |
47514034
|
[1] |
DISPLAY
|
CUR
Intel View IV
|
| 8. |
47514034R
|
[1] |
REMAN-ELECT MONITOR
|
RAC
Reman Intel View IV
|
| 8. |
47514034C
|
[1] |
CORE-MONITOR
|
RAC
Core Return Number
|
| 9. |
47520895
|
[1] |
WIRE HARNESS
|
NH
Incl 15, 17, 19 - 30 Superseded by part number: 47938505
|
| 10. |
47691332
|
[1] |
MOUNTING PLATE
|
NH
|
| 11. |
87742364
|
[4] |
SCREW,Pan Torx, M6 x 16mm, Cl 8.8
|
BRR
|
| 12. |
47538417
|
[1] |
WIRE HARNESS
|
NH
Optional, from Battery to Power Connector, Incl 17, 30 - 31
|
| 13. |
87537164
|
[1] |
WIRE HARNESS
|
PA
ANZ Light Harnerss Jumper
|
| 14. |
84279864
|
[1] |
ELEC CONNECTOR
|
PLO
Superseded by part number: 84068583
|
| 15. |
82017871
|
[2] |
RELAY,12V, 20A
|
BAS
Superseded by part number: 84411012
|
| 16. |
84058092
|
[2] |
CONTACT HOUSING,120 Ohm Resistor
|
ZED
|
| 17. |
83933689
|
[3] |
FUSE,10A, Red
|
ZED
Superseded by part number: 9811773
|
| 18. |
87717080
|
[1] |
FUSE,15A, Blue
|
COE
15 Amp Superseded by part number: 84090658
|
| 19. |
83932926
|
[2] |
FUSE,25A
|
ZED
Superseded by part number: 84100299
|
| 20. |
87693742
|
[1] |
FUSE,5A
|
BN
5 Amp
|
| 21. |
87601142
|
[1] |
ELEC CONNECTOR,Female, 6 Cavities
|
PLO
|
| 22. |
87612756
|
[1] |
CLAMP,25.4mm, Coat, 7.1mm Bolt Hole, P Type
|
PLO
|
| 23. |
617887
|
[1] |
HOOK
|
NH
|
| 24. |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 25. |
9804276
|
[1] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 26. |
9706703
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
NH
|
| 27. |
767456
|
[1] |
PLUG
|
NH
Superseded by part number: 87716289
|
| 28. |
87696184
|
[1] |
NUT
|
CUR
|
| 29. |
84607513
|
[1] |
LOCK WASHER
|
NH
|
| 30. |
787868
|
[1] |
BRACKET
|
NH
|
| 31. |
84157159
|
[1] |
FUSE,40A, Maxi, Orange
|
COE
|
| 32. |
47545581
|
[1] |
ROCKER SWITCH
|
NH
On/Off
|
