凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (55.905.AA[20]) - VAR - 726967, 726969 - WIRE HARNESS, ISOBUS, BETWEEN YFN18619 AND YGN190460 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
463 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47655927
|
[1] |
WIRE HARNESS
|
NH
ISOBUS, Between YFN188619 and YGN190460
|
| 2. |
87688716
|
[5] |
ELEC CONNECTOR,Female, 3 Cavities
|
FAR
|
| 3. |
87695582
|
[1] |
ELEC CONNECTOR,Female, 2 Pole
|
RAC
|
| 4. |
47690389
|
[2] |
|
ELEC CONNECTOR,Female, 3 Cavities
|
| 5. |
87695580
|
[1] |
ELEC CONNECTOR,Female, 3 Pole
|
BN
|
| 6. |
87700325
|
[1] |
ELEC CONNECTOR,Female, 8 Cavities
|
MKT
|
| 7. |
87693732
|
[1] |
LOCKING TAB,Wedge Lock
|
FAR
|
| 8. |
84074638
|
[1] |
LOCKING TAB,Locking Wedge, Green
|
ZED
|
| 9. |
84391159
|
[1] |
CAP
|
BN
|
| 10. |
84598834
|
[1] |
|
LOCKING TAB,Wedge Lock
|
| 11. |
84147090
|
[1] |
LOCKING TAB,Wedge Lock
|
CUR
|
| 12. |
84058092
|
[1] |
CONTACT HOUSING,120 Ohm Resistor
|
ZED
|
| 13. |
84806312
|
[1] |
LOCKING TAB,Wedge Lock
|
ZED
|
| 14. |
84391168
|
[1] |
|
CAP
|
| 16. |
87694714
|
[1] |
ELEC CONNECTOR,Female, 6 Cavities
|
ZED
Superseded by part number: 256348A1
|
| 17. |
47486969
|
[1] |
|
ELEC CONNECTOR,Female 3 Cavities, Red
|
| 18. |
84074639
|
[1] |
LOCKING TAB,Wedge Lock
|
ZED
Superseded by part number: 89842513
|
| 19. |
84391165
|
[1] |
HOUSING,Receptacle
|
BN
|
| 20. |
87601142
|
[1] |
ELEC CONNECTOR,Female, 6 Cavities
|
PLO
|
| 21. |
87694719
|
[1] |
LOCKING TAB,Wedge Lock
|
ZED
Superseded by part number: 258617A1
|
| 22. |
84277224
|
[1] |
|
LOCKING TAB,Wedge Lock
|
