神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (02-011) - OIL FILTER Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
493 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-15. | VAME054240 | [1] | ENGINE OIL FILTER | KOBM5 ONLY Superseded by part number: 133254A1 |
| . . | VAME059059 | [1] | M6 ONLY | |
| 1. | VA3094011101 | [1] | COVER | KOBHEAD, OIL FILTER |
| 2. | VA3124051203 | [2] | CASE | SMCASE, OIL FILTER, M5 ONLY Superseded by part number: VAME064111 |
| . . | NSS | [2] | NOT SOLD SEPARAT | CONM6 ONLY |
| 4-9. | VAME064356 | [1] | ENGINE OIL FILTER | KOBELEMENT KIT, NICHIRU Superseded by part number: 2451U180-1 |
| . . | VAME054334 | [1] | ENGINE OIL FILTER | KOBOR WAKO Superseded by part number: 360410A1 |
| 4-6. | VA3124053054 | [1] | ENGINE OIL FILTER | KOBOIL FILTER ELEMENT KIT, F/FLOW Superseded by part number: 360410A1 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONELEMENT, FULL FLOW |
| 5. | VA3124050301 | [1] | GASKET | KOBPACKING, RUBBER Superseded by part number: 133259A1 |
| 6. | VAMH035025 | [1] | O-RING | KOBO-RING Superseded by part number: 133268A1 |
| 7-9. | VAME054238 | [1] | ENGINE OIL FILTER | KOBELEMENT KIT, BY-PASS, WAKO Superseded by part number: 2451U166-1 |
| . . | VAME064354 | [1] | ELEMENT | KOBOR NICHIRO Superseded by part number: 2451U166-1 |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONELEMENT, BY-PASS |
| 8. | VA3124050301 | [1] | GASKET | KOBPACKING, RUBBER Superseded by part number: 133259A1 |
| 9. | VAMH035025 | [1] | O-RING | KOBO-RING Superseded by part number: 133268A1 |
| 10. | VAME054082 | [1] | RETAINER | KOBASSY, FULL FLOW Superseded by part number: 133262A1 |
| 11. | VAME054156 | [1] | RETAINER | KOBASSY, BY-PASS Superseded by part number: 133260A1 |
| 12. | VA3124050500 | [1] | BOLT | KOBBOLT, CTR, FULL FLOW |
| 13. | VA3124051500 | [1] | BOLT | KOBBOLT, CTR, BY-PASS |
| 14. | VA3124053900 | [2] | WASHER | KOBWASHER, CTR BOLT |
| 15. | VA3124050900 | [2] | PLUG | KOBPLUG Superseded by part number: 133271A1 |
| . . | VAMF660063 | [2] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 16. | VA3124054500 | [1] | O-RING | KOB Superseded by part number: 133272A1 |
| 17. | VA3113902201 | [2] | O-RING | KOB Superseded by part number: 133274A1 |
| 18. | VAMH000715 | [7] | SCREW | KOBBOLT, FLANGE 10X35 Superseded by part number: 133276A1 |
| 19. | VAME054661 | [1] | ALARM | KOBOIL BY-PASS Superseded by part number: 133255A1 |
| . . | VAMF660068 | [1] | PACKING | KOBGASKET 20 Superseded by part number: VAF420220000 |
