凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (60.220.AU[02]) - PICK-UP, WHEEL, LH, 4.80/4.00 X 8 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
786 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86604323
|
[2] |
RIM
|
PA
Incl 2 -
|
| 2. |
136378
|
[2] |
TYRE/TIRE
|
NH
Inner, 4 x 8
|
| 3. |
25447
|
[2] |
TIRE TUBE
|
NH
4 Ply, 4.80/4.00 x 8
|
| 4. |
86604252
|
[2] |
WHEEL
|
GI
Hub
|
| 5. |
136376
|
[2] |
SEAL,31.75mm ID x 50.42mm OD x 6.75mm Thk
|
NH
Oil
|
| 6. |
132709
|
[4] |
BEARING CUP,50.29mm OD x 10.67mm W
|
NH
|
| 7. |
132710
|
[4] |
BEARING CONE,25.4mm ID x 14.73mm W
|
NH
|
| 8. |
200734
|
[2] |
HUB CAP
|
NH
|
