| 1. |
86606742
|
[2] |
WHEEL ASSY
|
PA
Superseded by part number: 132710, 136376, 279538, 86609766, 200734, 132709, 86611311
|
| 2. |
84567999
|
[1] |
FORK
|
NH
LH
|
| 3. |
9839046
|
[4] |
WASHER,35.mm ID X 53mm OD X 2mm Thk
|
ZED
Superseded by part number: 89839046
|
| 4. |
370004
|
[2] |
SNAP RING,M35 x 1.5mm Thk, External
|
NH
Superseded by part number: 11068376
|
| 5. |
84012277
|
[2] |
KEY RING
|
ZED
|
| 6. |
84337334
|
[2] |
CHANNEL
|
PLO
|
| 7. |
84220857
|
[2] |
SPACER,12.7mm ID x 25.4mm OD x 70.5mm L
|
NH
|
| 8. |
9511052
|
[4] |
WASHER,13.5mm ID x 44mm OD x 4mm Thk
|
NH
|
| 9. |
140046
|
[2] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 10. |
374887
|
[2] |
BOLT,Hex, M12 x 1.75 x 100mm, Cl 8.8
|
NH
|
| 11. |
9804279
|
[2] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 12. |
84562237
|
[1] |
ARM
|
NH
Incl 25, 26
|
| 13. |
84567928
|
[1] |
FORK
|
NH
RH
|
| 14. |
87414
|
[2] |
LUBE NIPPLE,1/4" - 28
|
NH
|
| 15. |
87400
|
[2] |
COTTER PIN,3/16" x 2"
|
WIN
|
| 16. |
270184
|
[2] |
LINCH PIN,6.35mm OD
|
NH
|
| 17. |
47431237
|
[2] |
WIRE ROPE
|
NH
|
| 18. |
87056822
|
[2] |
PIN
|
PA
|
| 19. |
87398
|
[2] |
COTTER PIN,3/16" OD x 1-1/4" OAL
|
NH
|
| 20. |
84479182
|
[2] |
PIN,35mm OD x 207mm L
|
PLO
|
| 21. |
80700
|
[2] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 22. |
9509260
|
[2] |
LOCK BOLT,Hex, M12 x 40mm, Cl 8.8
|
ZED
|
| 23. |
603373
|
[2] |
JAM NUT,Slotted, 1" - 14, Gr 2
|
NH
Superseded by part number: 143183
|
| 24. |
26130
|
[2] |
WASHER,26mm ID x 35mm OD x 1.7mm Thk
|
NH
|
| 25. |
9615969
|
[2] |
SLEEVE,35mm ID x 39mm OD x 20mm L
|
ZED
|
| 26. |
84041902
|
[2] |
SEALING ELEMENT
|
ZED
|
