纽荷兰零件查询(CV900) - VIBRATORY ROLLER (9/01-) (10-003-00[01]) - HYDRAULIC CIRCUIT, TRAVEL - DRUM New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
958 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND103147 | [1] | SUPPORT | STA |
| 5. | ND052985 | [3] | STUD | STA |
| 7. | ND103175 | [1] | BRACKET | STA |
| 22. | ND067795 | [1] | VALVE | STA |
| 27. | ND062173 | [3] | HYD CONNECTOR | STA |
| 28. | ND062153 | [5] | HYD CONNECTOR | STA |
| 31. | ND062196 | [1] | HYD CONNECTOR | STA |
| 32. | ND062135 | [6] | HYD CONNECTOR | STA |
| 33. | ND062136 | [1] | HYD CONNECTOR | STA |
| 40. | ND062324 | [1] | HYD CONNECTOR | STA |
| 41. | ND062322 | [1] | HYD CONNECTOR | STA |
| 43. | ND062366 | [2] | ELBOW | STA |
| 47. | ND062338 | [1] | TEE | STA |
| 48. | ND062298 | [1] | HYD CONNECTOR | STA |
| 49. | ND062394 | [1] | HYD CONNECTOR | STA |
| 50. | ND062335 | [1] | HYD CONNECTOR | STA |
| 53. | ND062456 | [1] | HYD CONNECTOR | STA |
| 60. | ND062277 | [1] | QUICK FEMALE COUPLING | STA Superseded by part number: ND112940 |
| 61. | ND062280 | [1] | QUICK MALE COUPLING | STA Superseded by part number: ND112941 |
| 66. | ND062008 | [8] | HALF-COLLAR | STA |
| 68. | ND079933 | [4] | O-RING | STA |
| 82. | ND102237 | [1] | FLEXIBLE HOSE | STA3350mm |
| 83. | ND102239 | [1] | HOSE | STA1100mm |
| 87. | ND061234 | [1] | HOSE | STA700mm |
| 88. | ND102232 | [1] | HOSE,900.00 mm | STA |
| 90. | ND102230 | [1] | HOSE,2800.00 mm | STA |
| 91. | ND102231 | [1] | HOSE,3150.00 mm | STA |
| 101. | ND064799 | [1] | CLAMP | STA |
| 103. | ND064810 | [1] | SLEEVE | STA |
| 112. | ND024235 | [2] | BOLT | STAM5x 35 |
| 113. | ND024236 | [2] | BOLT | STAM6x 40 |
| 118. | ND021302 | [2] | BOLT | STAM10 x 25 |
| 119. | ND024259 | [8] | BOLT | STAM10 x 30 |
| 120. | ND021197 | [2] | BOLT | STAM10 x 45 |
| 123. | ND034059 | [24] | BOLT | STA |
| 129. | ND021847 | [3] | NUT | STAM6 |
| 131. | ND021849 | [2] | NUT | STAM10 Superseded by part number: ND034088 |
| 137. | ND029309 | [3] | SPRING WASHER | STAID 6,1 |
| 138. | ND035941 | [4] | WASHER | STAID 10 |
| 140. | ND029248 | [13] | WASHER | STAID 6,4 |
