神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (06-006) - WATER SEPARATOR Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
563 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-16. | VAME059754 | [1] | SEPARATOR | KOBWATER SEPARATOR ASSY |
| 1. | VAME069672 | [1] | COVER | KOB |
| 2. | VAME060628 | [1] | CASE WATER SEP | CASE WATER SEP |
| . . | VAME059640 | [1] | PLATE, CAUTION | |
| 3. | VAME060603 | [1] | NUT, RING | NUT, RING |
| 4. | VAME069680 | [1] | O-RING | KOBCASE Superseded by part number: 133377A1 |
| 5. | VAME069675 | [1] | PLATE,BAFFLE | PLATE,BAFFLE |
| 6. | VAME069679 | [1] | GASKET | KOB |
| 7. | VAME069676 | [1] | PLATE | KOBISOLATION |
| 8. | VAME069671 | [1] | SCREEN | KOB Superseded by part number: 133382A1 |
| 9. | VAME069677 | [1] | FLOAT | KOBLEVELING, WATER Superseded by part number: VAME158038 |
| 10. | VAME016812 | [1] | PLUG | KOBDRAIN |
| 11. | VAMF520085 | [1] | O-RING | KOBO-RING 10 Superseded by part number: VAF315101000 |
| 12. | VAMH037087 | [2] | BOLT | KOBBOLT, CONNECTOR 14 |
| 13. | VAMH035166 | [4] | GASKET | KOBGASKET 14 Superseded by part number: 133378A1 |
| 15. | VAMH037084 | [1] | GLOW PLUG | KOBPLUG, AIR Superseded by part number: 77270641, VAME016894 |
| 16. | VAMH035164 | [1] | GASKET | KOBGASKET 8 Superseded by part number: 133379A1 |
| 20. | VAME059566 | [1] | BBRACKET, WATER SEPARATOR | |
| 21. | VAMF140258 | [2] | BOLT,FLANGE(10X20) BOLT, FLANGE 10X20 | BOLT,FLANGE(10X20) BOLT, FLANGE 10X20 |
| 22. | VAMH005027 | [1] | WASHER | KOBWASHER |
| 23. | VAMH000713 | [2] | BOLT | KOBBOLT, FLANGE 10X20 |
| 24. | VAME910156 | [1] | HOSE | KOBFEED |
| 25. | VA3094290700 | [1] | STAY | KOBSTAY |
| 26. | VAMH020807 | [1] | CLIP | KOBCLAMP, HOSE |
| 27. | VAMH000999 | [1] | BOLT | KOBBOLT, FLANGE 6X12 |
| 28. | VA303606600 | [1] | PIPE, FUEL L=6000 | |
| 29. | VAMS666005 | [4] | CLIP CLAMP, HOSE 15 | CLIP CLAMP, HOSE 15 |
