卡特零件查询（725） 115-9397: ROCKER ARM GP
广数供应链运营团队, 14 02月, 2025，浏览：
591 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 115-9398 | [2] | ARM-VALVE ROCKER(EXHAUST) | |
| 2. | 115-9400 | [2] | ARM AS(UNIT INJECTION) | |
| | | | (EACH INCLUDES) |
| | 2D-6642 | [2] | BALL | |
| | 115-9402 | [1] | BEARING | |
| 3. | 115-9399 | [2] | ARM-VALVE ROCKER(INLET) | |
| 4. | 7C-1798 | [2] | SCREW-ARM ADJUSTMENT | |
| 5. | 245-6095 | [2] | NUT-HEX THIN(M12X1.5-THD) | |
| 6. | 258-8721 | [2] | BUTTON | |
| 7. | 8L-2777 | [2] | SEAL-O-RING | |
| 8. | 115-9403 | [2] | SHAFT AS | |
| | | | (EACH INCLUDES) |
| 9. | 3S-6605 | [1] | PLUG-CUP | |
| 10. | 096-0014 | [1] | PIN-SPRING | |
| 11. | 185-4461 | [2] | SUPPORT AS | |
| | | | (EACH INCLUDES) |
| 12. | 180-1538 | [2] | DOWEL | |
| 13. | 183-4365M | [4] | SCREW-ADJUSTMENT(M10X1.5-THD) | |
| 14. | 2Y-5829M | [4] | NUT(M10X1.5-THD) | |
| | M | | METRIC PART |
| | R | | REMANUFACTURED PART MAY BE AVAILABLE |
