卡特零件查询（725） 117-2749: VALVE MECHANISM GP
广数供应链运营团队, 14 02月, 2025，浏览：
814 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 9X-8267 | [4] | WASHER(6.6X12X2-MM THK) | |
| 2. | 8T-0275M | [4] | BOLT(M6X1X50-MM) | |
| 3. | 3E-4352 | [8] | WASHER-HARD(8.8X20.5X2.5-MM THK) | |
| 4. | 8T-0100M | [16] | BOLT(M8X1.25X60-MM) | |
| 5. | 7C-8292 | [8] | ISOLATOR | |
| 6. | 9Y-7215 | [8] | SLEEVE-ISOLATOR | |
| 7. | 9Y-4357 | [1] | BREATHER AS(CRANKCASE) | |
| 8. | 9Y-1758 | [1] | GASKET(CRANKCASE BREATHER) | |
| 9. | 102-5842 | [1] | BASE-VALVE MECHANISM COVER | |
| 10. | 109-5309 | [1] | GASKET-VALVE COVER | |
| 11. | 115-9397Y | [3] | ROCKER ARM GP | |
| 12. | 148-2063CY | [2] | LIFTER GP-VALVE | |
| 13. | 104-3567 | [12] | PUSHROD-VALVE | |
| 14. | 104-3568 | [6] | PUSHROD | |
| 15. | 9M-1974 | [9] | WASHER-HARD(8.8X16X2-MM THK) | |
| 16. | 6V-5217M | [1] | BOLT(M8X1.25X20-MM) | |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
