凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (60.260.CC[01]) - ROTOR FEEDER, DROP FLOOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
281 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84513341
|
[1] |
ROTOR
|
PLO
Feeder
|
| 2. |
47837508
|
[1] |
SHEET
|
NH
LH
|
| 3. |
47837500
|
[1] |
SHEET
|
NH
RH
|
| 4. |
47917110
|
[1] |
RAKE
|
NH
|
| 5. |
47837398
|
[1] |
FLOOR
|
NH
|
| 6. |
84309329
|
[1] |
SHEET
|
PLO
LH
|
| 7. |
84309324
|
[1] |
STRIP
|
PLO
RH
|
| 8. |
87648312
|
[11] |
CHANNEL
|
NH
|
| 9. |
47534410
|
[2] |
SHAFT,30mm OD x 120mm L
|
PLO
|
| 10. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Rotor Drives
|
| 11. |
87648668
|
[4] |
SHIM,125mm OD x 1mm Thk
|
NH
|
| 12. |
84416740
|
[1] |
FLOOR
|
PLO
Drop
|
| 13. |
87029395
|
[2] |
CYLINDER ASSY.,Double Acting, 19.05mm Rod, 119.89mm Stroke
|
PA
|
| 14. |
80708
|
[2] |
COTTER PIN,1/8" x 1 1/2"
|
NH
|
| 15. |
9804261
|
[26] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 16. |
86512446
|
[3] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 17. |
9804265
|
[2] |
FLANGE BOLT,Hex, M10 x 60mm, Cl 8.8
|
NH
|
| 18. |
9670066
|
[4] |
FLANGE BOLT,Hex, M12 x 30mm, Cl 8.8
|
NH
|
| 19. |
87365
|
[2] |
WASHER,0.66" ID x 1.31" OD x 0.1" Thk
|
NH
|
| 20. |
9804278
|
[7] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 21. |
441176
|
[2] |
WASHER,31mm ID x 45mm OD x 0.87mm Thk
|
ZED
|
| 22. |
140017
|
[6] |
WASHER,M10 x 20mm OD x 2mm Thk
|
PA
Superseded by part number: 9820489
|
| 23. |
374892
|
[2] |
CARRIAGE BOLT,M10 x 1.5 x 40mm, Cl 8.8
|
NH
|
