| 1. |
84513336
|
[1] |
ROTOR
|
PLO
Cutter, Drop Floor
|
| 2. |
47837508
|
[1] |
SHEET
|
NH
LH
|
| 3. |
47837500
|
[1] |
SHEET
|
NH
RH
|
| 4. |
47722689
|
[1] |
RAKE
|
NH
Superseded by part number: 47917116
|
| 5. |
47837398
|
[1] |
FLOOR
|
NH
|
| 6. |
84309329
|
[1] |
SHEET
|
PLO
LH
|
| 7. |
84309324
|
[1] |
STRIP
|
PLO
RH
|
| 8. |
84309333
|
[16] |
STRIPPER
|
PLO
Center
|
| 9. |
87649169
|
[1] |
SHAFT
|
NH
|
| 10. |
84415133
|
[1] |
ROD
|
PLO
|
| 11. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Rotor Drives
|
| 12. |
87648668
|
[4] |
SHIM,125mm OD x 1mm Thk
|
NH
|
| 13. |
87649286
|
[15] |
KNIFE ASSY
|
NH
|
| 14. |
58630
|
[2] |
WASHER,.0299" Thk
|
NH
|
| 15. |
87029395
|
[3] |
CYLINDER ASSY.,Double Acting, 19.05mm Rod, 119.89mm Stroke
|
PA
|
| 16. |
151990
|
[1] |
SPRING,22.2mm OD x 127mm L
|
NH
|
| 17. |
372783
|
[1] |
KNOB
|
ZED
|
| 18. |
130045
|
[1] |
PIN,5mm OD x 26mm L, Slotted
|
NH
|
| 19. |
80708
|
[4] |
COTTER PIN,1/8" x 1 1/2"
|
NH
|
| 20. |
80714
|
[1] |
LUBE NIPPLE,1/4"-28 NPT x .54" lg
|
PA
Superseded by part number: 87414
|
| 21. |
9804261
|
[36] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 22. |
86512446
|
[3] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 23. |
9804266
|
[4] |
BOLT,Hex, M12 x 25mm, Cl 8.8, Full Thd
|
DUB
|
| 24. |
9706687
|
[1] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 25. |
9706691
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
|
SAS
|
| 26. |
80700
|
[1] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 27. |
87365
|
[4] |
WASHER,0.66" ID x 1.31" OD x 0.1" Thk
|
NH
|
| 28. |
140017
|
[6] |
WASHER,M10 x 20mm OD x 2mm Thk
|
PA
Superseded by part number: 9820489
|
| 29. |
9804278
|
[5] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 30. |
9706685
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 31. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 32. |
86977759
|
[1] |
BOLT,Hex, 3/4" - 10 x 3 1/2", Gr 5
|
FTR
|
| 33. |
84415132
|
[1] |
PIN,16mm OD x 62.6mm L
|
PLO
|
| 34. |
9626598
|
[1] |
NUT,3/4"-10, GB
|
PA
Superseded by part number: 280375
|
