| 1. |
84415116
|
[1] |
SUPPORT
|
PLO
|
| 2. |
84416798
|
[1] |
SUPPORT
|
PLO
|
| 3. |
84415118
|
[1] |
SHAFT
|
PLO
|
| 4. |
84474129
|
[1] |
PLATE
|
PLO
|
| 5. |
84039309
|
[4] |
COVER PLATE
|
ZED
|
| 6. |
84038524
|
[15] |
SPRING,Compression, 1.26" OD x 13.39" L
|
ZED
|
| 7. |
86050286
|
[1] |
FLANGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 8. |
84415126
|
[1] |
CHANNEL
|
PLO
|
| 9. |
84041936
|
[15] |
ROLLER,25mm OD x 15mm L
|
ZED
|
| 10. |
84414312
|
[1] |
FLOOR
|
PLO
|
| 11. |
511603
|
[30] |
WASHER,15.48mm ID x 25.4mm OD x 2.14mm Thk
|
NH
|
| 12. |
321204
|
[2] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 13. |
84039310
|
[2] |
HEX PLUG,44mm L
|
ZED
|
| 14. |
84041862
|
[30] |
CIRCLIP
|
ZED
|
| 15. |
170019
|
[2] |
KEY,14mm x 9mm x 40mm
|
NH
|
| 16. |
84039463
|
[2] |
LEVER
|
ZED
|
| 17. |
84068634
|
[15] |
LEVER
|
ZED
|
| 18. |
87652185
|
[15] |
ARM
|
PLO
|
| 19. |
80752
|
[1] |
COTTER PIN,1/4" x 2 1/2"
|
BHB
|
| 20. |
84043787
|
[30] |
PIN
|
ZED
Superseded by part number: 87652359
|
| 21. |
412202
|
[2] |
LOCK PIN,8mm OD x 65mm L, Slotted
|
PA
|
| 22. |
380840
|
[2] |
CLEVIS PIN,M16 x 30
|
NH
|
| 23. |
80755
|
[2] |
COTTER PIN,1/8" OD x 1" L
|
NH
|
| 24. |
9804279
|
[4] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 25. |
9804278
|
[4] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 26. |
84415125
|
[1] |
SPACER,45.3mm ID x 59.18mm OD x 33.5mm L
|
PLO
|
| 27. |
86609647
|
[1] |
SPACER,960mm L x 10mm Thk
|
NH
|
| 28. |
86610340
|
[2] |
SPACER,46.25mm ID x 57.53mm OD x 11mm L
|
NH
|
| 29. |
84410341
|
[13] |
SHIM
|
S
|
| 30. |
84415124
|
[2] |
SPACER,45.3mm ID x 59.18mm OD x 22.4mm L
|
PLO
|
| 31. |
86507486
|
[1] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 32. |
120104
|
[15] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 33. |
9804258
|
[3] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 34. |
9804262
|
[4] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 35. |
9670066
|
[6] |
FLANGE BOLT,Hex, M12 x 30mm, Cl 8.8
|
NH
|
| 36. |
9804277
|
[1] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 37. |
165238
|
[22] |
WASHER,45.2mm ID x 63.5mm OD x 1.24mm Thk
|
PA
Superseded by part number: T42195
|
| 38. |
86619043
|
[1] |
WASHER,45.2mm ID x 60.3mm OD x 3.68mm Thk
|
NH
|
| 39. |
58821
|
[1] |
WASHER,45.24mm ID x 56.36mm OD x 1.65mm Thk
|
NH
|
| 40. |
140020
|
[32] |
WASHER,17.5mm ID x 30mm OD x 3mm Thk
|
NH
|
| 41. |
86629542
|
[15] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
