神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (03-002) - FUEL INJECTION PUMP GENERAL 040-130H Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
212 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-5. | VAME157073 | [1] | INJECTION PUMP, EXCH | KOBGENERAL, (DKC 1066732021) |
| 1. | VAME059751 | [1] | INJECTION PUMP ASSY, P TYPE, Serial Range: GN040-GN131B | |
| 2. | VAME726398 | [1] | GOVERNOR ASSY, RSV TYPE GN040, Serial Range: -GN132F | |
| 3. | VAME059636 | [1] | PUMP | KOBASSY, K TYPE, Serial Range: GN040-GN133A Superseded by part number: 133424A1 |
| 4. | VAME723861 | [1] | AUTOMATIC T ASSY, SP TYPE GN040, Serial Range: -GN134B | AUTOMATIC T ASSY, SP TYPE GN040, Serial Range: -GN134B |
| 5. | VAME056242 | [1] | COUPLING | KOBCOUPLING ASSY, Serial Range: GN040-GN135A |
| 14. | VAME056381 | [1] | U-BRACKET | KOBBRACKET, I/P Superseded by part number: 133425A1 |
| 15. | VAMS471107 | [2] | BUSHING | KOBBUSHING, KNOCK 10X9 |
| 16. | VAMH000715 | [4] | SCREW | KOBBOLT, FLANGE 10X35 Superseded by part number: 133276A1 |
| 17. | VAMH000724 | [4] | SCREW | KOBBOLT, FLANGE 10X85 Superseded by part number: 132669A1 |
| 19. | VA3016101200 | [1] | SHIM | KOBT=0.1 Superseded by part number: 133429A1 |
| 19. | VA3116101800 | [1] | SHIM | KOBSHIM T=0.2 Superseded by part number: 3116101800 |
