| 1. |
84423609
|
[1] |
ROLL
|
NH
Drive
|
| 2. |
86610088
|
[1] |
ROLLER
|
NH
Floor Superseded by part number: 87660299
|
| 3. |
84471018
|
[1] |
ROLL,254mm OD x 1475mm L
|
PLO
Fixed Superseded by part number: 47832087
|
| 4. |
87664059
|
[2] |
DISK
|
NH
|
| 5. |
47536123
|
[2] |
SHIELD
|
PLO
|
| 6. |
9804278
|
[1] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 7. |
86590752
|
[1] |
BEARING ASSY
|
NH
Superseded by part number: 87660333
|
| 8. |
86609558
|
[1] |
BEARING ASSY,45mm ID
|
NH
|
| 9. |
86590753
|
[2] |
BEARING ASSY
|
NH
|
| 10. |
52443
|
[2] |
BALL BEARING,38.1mm ID x 79.99mm OD x 22mm W
|
NH
Superseded by part number: 664073R92
|
| 11. |
52444
|
[2] |
COLLAR,38.2mm ID x 60.33mm OD x 18.3mm Thk
|
NH
Superseded by part number: 47577185
|
| 12. |
86974037
|
[2] |
FLANGE
|
GI
|
| 13. |
140046
|
[20] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 14. |
140048
|
[4] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 15. |
86531147
|
[8] |
BOLT,Hex, M10 x 16mm, Cl 8.8, Full Thd
|
NH
|
| 16. |
300389
|
[12] |
BOLT,M12 x 1.75 x 35mm, Cl 8.8
|
NH
Superseded by part number: 628-12035
|
| 17. |
9628065
|
[8] |
SCREW,Hex, M12 x 1.75 x 45mm, Cl 8.8
|
NH
|
| 18. |
43168
|
[4] |
BOLT,Hex, M16 x 40mm, Cl 8.8
|
NH
Superseded by part number: 86509867
|
| 19. |
9804279
|
[4] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 20. |
47637045
|
[1] |
SHIELD
|
PLO
|
| 21. |
47536134
|
[1] |
PLATE
|
PLO
|
| 22. |
9804258
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 23. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
