神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (03-011) - FUEL FEED PUMP (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
281 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-36. | VA3096100700 | [1] | SENDER UNIT | KOBFUEL FEED PUMP ASSY, KE TYPE, M0 ONLY, (3126170300) Superseded by part number: VA1052104151 |
| 1-42. | VAME059636 | [1] | PUMP | KOBASSY, K TYPE, M3 ONLY Superseded by part number: 133424A1 |
| 1. | VAME705128 | [1] | HOUSING FEE PUMP, M0 ONLY | HOUSING FEE PUMP, M0 ONLY |
| . . | VAME705084 | [1] | M3 ONLY | |
| 5. | VAME705020 | [1] | PISTON | KOB Superseded by part number: VA1521001120 |
| 6. | VAME705021 | [1] | SPRING | KOBPISTON |
| 7. | VAME705022 | [1] | PLUG | KOB |
| 8. | VAME705275 | [1] | GASKET | KOB Superseded by part number: VA0293326030 |
| 10. | VAME705023 | [1] | TAPPET ASSY, M0 ONLY | |
| . . | VAME705051 | [1] | TAPPET | KOBASSY, M3 ONLY |
| 14. | VAME705027 | [2] | VALVE | KOB Superseded by part number: VA1521150200, 77270043 |
| 15. | VAME705028 | [2] | SPRING | KOB Superseded by part number: 77270044, VA1521160200 |
| 16. | VAME705029 | [1] | PLUG | KOBM0 ONLY |
| . . | VAME717648 | [1] | PLUG | KOBM3 ONLY |
| 18. | VAME705276 | [2] | PACKING | KOBGASKET Superseded by part number: VA0293316030, 77270063 |
| 20. | VAME705030 | [1] | RING | KOBSNAP |
| 25. | VAME705031 | [1] | ENGINE OIL PUMP | KOBPRIMING, M0 ONLY Superseded by part number: VA1522001120 |
| . . | VAME705055 | [1] | ENGINE OIL PUMP | KOBPRIMING, M3 ONLY |
| 30. | VAME717651 | [1] | SPOOL | KOB |
| 32. | VAME705216 | [1] | BOLT | KOBEYE |
| 35. | VA3126106400 | [2] | GASKET | KOB Superseded by part number: VA0293414130 |
| 36. | VA3126106400 | [2] | GASKET | KOB Superseded by part number: VA0293414130 |
| 42. | VAME705033 | [1] | COVER | KOBM3 ONLY |
