神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (03-015) - COUPLING (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
554 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-21. | VAME056100 | [1] | COUPLING | KOBCOUPLING ASSY, M0 ONLY (3096100600) |
| 1-21B. | VAME056242 | [1] | COUPLING | KOBCOUPLING ASSY, M1 ONLY |
| 1. | VAME716602 | [1] | COUPLING M0 ONLY | COUPLING M0 ONLY |
| . . | VAME717635 | [1] | M1 ONLY | |
| 2. | VAME716603 | [2] | BOLT | KOBM1 ONLY |
| . . | VAME717636 | [2] | M1 ONLY | |
| 3. | VAME716604 | [2] | WASHER M0 ONLY | WASHER M0 ONLY |
| . . | VAME717637 | [2] | WASHER | KOBM1 ONLY Superseded by part number: VA1566152800 |
| 4. | VAME716605 | [1] | PLATE | KOBM0 ONLY Superseded by part number: VA1566053520 |
| . . | VAME717638 | [1] | COUPLING M1 ONLY | COUPLING M1 ONLY |
| 5. | VAMF450405 | [2] | WASHER | KOBWASHER, SPG, M0 ONLY Superseded by part number: 132502A1 |
| 7. | VAME716606 | [2] | BOLT M0 ONLY | BOLT M0 ONLY |
| . . | VAME717639 | [2] | SCREW | KOBM1 ONLY |
| 8. | VAME450405 | [2] | WASHER, SPG, M1 ONLY | |
| 10. | VAME716754 | [2] | NUT M0 ONLY | NUT M0 ONLY |
| 11. | VAME716607 | [1] | COUPLING | KOBM0 ONLY |
| . . | VAME717640 | [1] | M1 ONLY | |
| 12. | VAME716606 | [22] | BOLT M0 ONLY | BOLT M0 ONLY |
| 13. | VAMF450405 | [2] | WASHER | KOBWASHER, SPG, M0 ONLY Superseded by part number: 132502A1 |
| 15. | VAME716754 | [2] | NUT M0 ONLY | NUT M0 ONLY |
| 16. | VAME716608 | [1] | PLATE | KOBM0 ONLY |
| . . | VAME717641 | [1] | COUPLING | KOBM1 ONLY |
| 17. | VAME705017 | [2] | BOLT M0 ONLY | BOLT M0 ONLY |
| 18. | VAMF450405 | [2] | WASHER | KOBWASHER, SPG, M0 ONLY Superseded by part number: 132502A1 |
| . . | VAME705221 | [2] | M1 ONLY | |
| 20. | VAME716609 | [1] | BOLT, M0 ONLY | |
| . . | VAME705064 | [1] | BOLT | KOBM1 ONLY Superseded by part number: VA1566037200 |
| 21. | VAME705221 | [1] | WASHER,SPG, M0 ONLY | |
| 21B. | VAME705065 | [1] | WASHER | KOBPLAIN, M1 ONLY Superseded by part number: VA1566152600 |
