凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (62.140.AI[03]) - DRIVE CHAIN, LH, OVERSHOT FEEDER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
668 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
9804061
|
[1] |
CHAIN,80, 84 Links x 25.4mm = 2133.6mm
|
NH
Incl 11
|
| 2. |
86520083
|
[1] |
CHAIN,RC80, 144 Total Pitches
|
PA
Incl 11 Superseded by part number: 86545866
|
| 3. |
87021804
|
[1] |
CHAIN,Roller, 68 Links x 25.4mm = 1727.2mm
|
PA
Incl 11
|
| 4. |
84597734
|
[1] |
CHAIN,60H-2, 69 Links x 19.05mm = 1314.45mm L
|
NH
RC60 Double Strand, 69 Pitches, Incl 12, 14
|
| 5. |
84262617
|
[1] |
ARM
|
NH
Idler, Incl 13, Serial Range: -YFN188618 Superseded by part number: 47748078
|
| 5. |
47748078
|
[1] |
ARM
|
NH
Idler, Incl 13, Start Serial: YFN188619
|
| 6. |
84271552
|
[2] |
IDLER,50.8mm OD x 56mm L
|
NH
|
| 7. |
84266904
|
[1] |
PLATE
|
NH
|
| 8. |
80700
|
[3] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 9. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 10. |
86508581
|
[2] |
BOLT,Hex, M12 x 90mm, Cl 8.8
|
NH
|
| 11. |
84356440
|
[3] |
LINK,25.4mm Pitch
|
NH
|
| 12. |
84605997
|
[1] |
LINK,RC60H-2, 19.1mm Pitch
|
NH
|
| 13. |
84019797
|
[1] |
SLEEVE,25mm ID x 28mm OD x 25mm L
|
NH
Superseded by part number: 604085
|
| 14. |
84605986
|
[1] |
OFFSET LINK,RC60H-2, 19.1mm Pitch
|
NH
|
