凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (62.140.AJ[02]) - DRIVE IDLERS, LH Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
517 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84582052
|
[1] |
ARM
|
NH
Idler, Fixed Roll
|
| 2. |
84582051
|
[1] |
ARM
|
NH
Idler, Starter Roll
|
| 3. |
87400
|
[1] |
COTTER PIN,3/16" x 2"
|
WIN
|
| 4. |
84401598
|
[2] |
SPROCKET,39.967mm ID x 118.4mm OD x 14.61mm Thk
|
GI
13T, RC80, Incl 23 Superseded by part number: 87011880
|
| 5. |
86637258
|
[2] |
TUBE,19.05 mm OD x 228.60 mm L
|
NH
|
| 6. |
86643093
|
[2] |
INDICATOR
|
NH
|
| 7. |
86618710
|
[3] |
SPRING,1-3/8" OD x 8-5/8" L
|
NH
|
| 8. |
87653298
|
[3] |
SPACER,13.49mm ID x 25.4mm OD x 9.53mm Thk
|
NH
|
| 9. |
84293932
|
[1] |
ARM
|
PLO
Idler, Floor Roll
|
| 10. |
47395966
|
[1] |
SPROCKET,RC60, 13T
|
NH
Incl 23
|
| 11. |
142656
|
[1] |
WASHER,33.35mm ID x 47.63mm OD x 3.43mm Thk
|
NH
|
| 12. |
87365
|
[5] |
WASHER,0.66" ID x 1.31" OD x 0.1" Thk
|
NH
|
| 13. |
80700
|
[9] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 14. |
26402
|
[2] |
WASHER,25.8mm ID x 38.1mm OD x 1.7mm Thk
|
NH
|
| 15. |
86000441
|
[3] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 16. |
9706685
|
[6] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 17. |
100038
|
[3] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 18. |
86633971
|
[3] |
BOLT,M12 x 1.75 x 377.5mm L
|
NH
|
| 19. |
120046
|
[2] |
CARRIAGE BOLT,M16 x 60mm, Cl 8.8
|
ZED
Superseded by part number: 87552612
|
| 20. |
120090
|
[1] |
BOLT,Hex, M16 x 50mm, Cl 8.8
|
NH
|
| 21. |
300389
|
[3] |
BOLT,M12 x 1.75 x 35mm, Cl 8.8
|
NH
Superseded by part number: 628-12035
|
| 22. |
9670066
|
[1] |
FLANGE BOLT,Hex, M12 x 30mm, Cl 8.8
|
NH
|
| 23. |
66553
|
[1] |
BALL BEARING,16.13mm ID x 40mm OD x 12.12mm W
|
NH
|
