纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (10.400.BE[05]) - RADIATOR AND OIL COOLER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
647 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84588263 | [1] | RADIATOR | BUR Superseded by part number: 47576423 |
| 2. | 84588262 | [1] | OIL COOLER | BUR Superseded by part number: 47576422 |
| 3. | 84473684 | [2] | RADIATOR HOSE | BUR Superseded by part number: 8501025 |
| 4. | 254026A1 | [8] | HOSE CLAMP,44.45mm - 66.67mm | CAS |
| 5. | 47384058 | [1] | HYD. TUBE | BURAssembly, Cooler Outlet Superseded by part number: 47583077 |
| 6. | 86637693 | [1] | ; Incl 5 | NUT |
| 7. | 86639098 | [1] | TUBE NUT | FARORFS 1, 11/16; Incl 5 |
| 8. | 87530407 | [1] | ; Incl 5 | |
| 9. | 43138 | [4] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8 | NH |
| 10. | 515-24317 | [1] | CLAMP,1 1/4", Insul, 7/16" Bolt | CAS |
| 11. | 84481462 | [1] | RIGID TUBE | BURRadiator, Up |
| 12. | 86624005 | [1] | CLAMP,19mm, Coat, 10.3mm Bolt Hole, P Type | FOR |
| 13. | 515-23444 | [1] | CLAMP,1 3/4", Insul, 3/8" Bolt | CAS Superseded by part number: 603022 |
| 14. | 86625234 | [1] | DRAINCOCK/TAP SUPPLY,1/4" NPTF | FARValve, 1/4 NPTF Drain |
| 15. | 84481472 | [2] | ELBOW,50.8mm ID x 103.6mm L, SAE J20R4, Class D1 | BURRadiator, Epdm |
| 16. | 84531917 | [1] | TUBE | BURRadiator, Lower |
| 17. | 76349 | [1] | PLUG,9/16" - 18 ORB | NH |
| 18. | 9617873 | [1] | O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro | NH; Incl 17 |
| 19. | 84556842 | [2] | SEAL,690mm L | BUR |
| 20. | 84481481 | [3] | SEALING STRIP,900mm L | BUR |
| 21. | 84570346 | [8] | ISOLATOR,20mm ID x 53mm OD x 21mm L | BUR |
| 22. | 43233 | [4] | BOLT,Hex, M10 x 1.25 x 20mm, Cl 8.8, Full Thd | NH |
| 23. | 84556841 | [1] | RUBBER SEAL,680mm L | BUR |
