| 1. | 84570385 | [1] | RADIATOR PANEL | BUR Superseded by part number: 47591888 |
| 2. | 47534767 | [1] | FRAME | BUR Superseded by part number: 47593963 |
| 3. | 84570398 | [1] | RADIATOR PANEL | BUR Superseded by part number: 47591898 |
| 4. | 84570403 | [1] | RADIATOR PANEL | BUR Superseded by part number: 47591878 |
| 5. | 47487138 | [1] | SHROUD | BUR |
| 6. | 47532088 | [1] | SHROUD | BUR Superseded by part number: 47578889 |
| 7. | 84588262 | [1] | OIL COOLER | BUR Superseded by part number: 47576422 |
| 8. | 84588263 | [1] | RADIATOR | BUR Superseded by part number: 47576423 |
| 9. | 84588264 | [1] | COOLER ASSY. | BUR |
| 10. | 82019588 | [1] | COOLANT EXPANSION RESERVOIR | BAS |
| 11. | 84564876 | [1] | BRACKET | BUR |
| 12. | 84556841 | [1] | RUBBER SEAL,680mm L | BUR |
| 13. | 87655043 | [6] | WASHER,M12, 13.65mm ID x 24.90mm OD x 3.20mm, HT Boron, ZNM | BUR |
| 14. | 614-12050 | [8] | BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8, Full Thd | CAS Superseded by part number: 87342144 |
| 15. | 84570346 | [8] | ISOLATOR,20mm ID x 53mm OD x 21mm L | BUR |
| 16. | 84481474 | [4] | ISOLATOR | BUR |
| 17. | 84481473 | [2] | ISOLATOR | BUR |
| 18. | 84556842 | [2] | SEAL,690mm L | BUR |
| 19. | 84556839 | [2] | SEALING STRIP,1100mm L | BUR |
| 20. | 47525524 | [1] | SEAL | BUR |
| 21. | 87655046 | [12] | SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk | BUR |
| 22. | 9861444 | [16] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9 | BHB Superseded by part number: 11106031 |
| 23. | 87026355 | [4] | WASHER,12.8mm ID x 50mm OD x 3mm Thk | GI |
| 24. | 86977776 | [2] | BOLT,Hex, M12 x 70mm, Cl 8.8, Full Thd | PA Superseded by part number: 9706717 |
| 25. | 87497916 | [2] | NUT | BRR Superseded by part number: 87497918 |
| 26. | 86624147 | [4] | WASHER,0.53" ID x 1.5" OD x 0.12" Thk | FOR |
| 27. | 82022744 | [1] | CAP | BAS |
| 28. | 87655042 | [4] | SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk | BUR |
| 29. | 43233 | [4] | BOLT,Hex, M10 x 1.25 x 20mm, Cl 8.8, Full Thd | NH |
| 30. | 47538765 | [1] | SHROUD | BUR |
| 31. | 47538755 | [1] | SHROUD | BUR |
| 32. | 906091R1 | [2] | SPACER,10.7mm ID x 17.14mm OD x 9.5mm L | WIC |
| 33. | 86624005 | [2] | CLAMP,19mm, Coat, 10.3mm Bolt Hole, P Type | FOR |
| 34. | 87026053 | [2] | BOLT,Hex, M10 x 1.25 x 30mm, Cl 10.9, Full Thd | RAC |
