| 1. | 84561131 | [1] | HYDRAULIC HOSE,25.4mm ID x 880mm L, SAE 100R15 | BURO-Rings Not Included |
| 2. | 9628065 | [24] | SCREW,Hex, M12 x 1.75 x 45mm, Cl 8.8 | NH |
| 3. | 86625255 | [24] | WASHER,13.3mm ID x 24.5mm OD x 3mm Thk | GI |
| 4. | 86980732 | [14] | CLAMP | GI |
| 5. | 84574231 | [1] | HYDRAULIC HOSE,25.4mm ID x 950mm L, SAE 100R15 | BURMotor to Manifold |
| 6. | 238-6220 | [10] | O-RING,0.139" Thk x 1.359" ID, -220, Cl 6, 90 Duro | CAS Superseded by part number: 70925934 |
| 7. | 84561120 | [1] | HYDRAULIC HOSE,25.4mm ID x 915mm L, SAE 100R15 | BURPump to Motot Rear Right |
| 8. | 84499033 | [1] | HYDRAULIC HOSE,19.05mm ID x 1295mm L, SAE 100R1 | BURMotor to Manifold |
| 9. | 84561099 | [1] | HYDRAULIC HOSE,9.53mm ID x 611mm L, SAE 100R16 | BURPump to Motor |
| 10. | 84574264 | [1] | HYDRAULIC HOSE,15.88mm ID x 937mm L, SAE 100R16 | BURPump to Manifold |
| 11. | 84561121 | [1] | HYDRAULIC HOSE,19.05mm ID x 700mm L, SAE 100R1 | BURPump to Manifold T1 - TP1 |
| 12. | 9846848 | [2] | 90 ELBOW,1-3/16"-12 ORFS x 1-1/16"-12 ORB | NH |
| 13. | 84499030 | [1] | HYDRAULIC HOSE,19.05mm ID x 675mm L, SAE 100R1 | BURPump to Manifold T2 - TP1 |
| 14. | 84561115 | [1] | HYDRAULIC HOSE,25.4mm ID x 890mm L, SAE 100R15 | BURMotor to Manifold |
| 15. | 9992307 | [2] | 90 ELBOW,90º, 13/16"-16 x 3/4"-16 Adj, ORFS | WIN |
| 16. | 86529541 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | ZED |
| 17. | 9824050 | [1] | O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro | WIN Superseded by part number: 87473574 |
