纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (35.104.AA[01]) - WINCH PROVISION PUMP W/O PTO New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
159 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84323337 | [1] | HYDRAULIC PUMP,64.56 CC | BUR |
| . . | 84323337R | [1] | REMAN-HYD PUMP | BUR1150M |
| . . | 84323337C | [1] | CORE-HYDRAULIC PUMP | BURReturn Number |
| 2. | 70921117 | [2] | FLANGE | BHB Superseded by part number: 714308 |
| 3. | 81547 | [4] | BEARING WASHER,7/16" | NH |
| 4. | 9637916 | [4] | BOLT,Hex, 7/16" - 14 x 1 1/2", Gr 5 | NH |
| 5. | A14157 | [2] | FLANGE | CAS |
| 6. | 80679 | [4] | LOCK WASHER,1/20.507 CST ZND | NH |
| 7. | 87689 | [4] | BOLT,1/2"-13 x 1.813" OAL, Cl 5 | NH |
| 8. | 84491001 | [1] | HOSE ASSY.,38mm ID x 854mm L, SAE 100R4 | BUR |
| 9. | 47574089 | [1] | HOSE | BUR |
| 10. | 87655043 | [4] | WASHER,M12, 13.65mm ID x 24.90mm OD x 3.20mm, HT Boron, ZNM | BUR |
| 11. | 300389 | [4] | BOLT,M12 x 1.75 x 35mm | NH Superseded by part number: 628-12035 |
| 12. | 201-134 | [1] | HYD CONNECTOR,1 11/16"-12 ORFS x 1 5/16"-12 ORB | CAS |
| 13. | 201-359 | [1] | ELBOW,90º, 1 11/16"-12 x 1 11/16"-12 Fem Sw ORFS | CAS |
| 14. | 84180945 | [1] | COLLAR CLAMP,1.87" - 2.18" | CUR Superseded by part number: 86050202 |
| 15. | 87632735 | [1] | O-RING,1.859" ID x 2.137" OD x 0.139" | SAS |
| 16. | 235757 | [1] | O-RING,0.139" Thk x 1.484" ID, -222, Cl 6, 90 Duro | WIN |
| 17. | 9824051 | [1] | O-RING,0.07" Thk x 1.176" ID, -25, Cl 6, 90 Duro | WIN |
