纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (35.104.AA[02]) - WINCH PROVISION PUMP W/ PTO New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
495 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87331905 | [1] | HYDROSTATIC PUMP,65.6 CC | BUR |
| 1. | 87331905R | [1] | REMAN-HYDROSTATIC PUMP | BUR |
| 1. | 87331905C | [1] | CORE-HYDROSTATIC PUMP | BURReturn Number |
| 2. | 9846956 | [1] | 90 ELBOW,90°, 1-7/16"-12 x 1-1/16"-12, Adj, ORFS | BAS |
| 3. | 87655043 | [4] | WASHER,M12, 13.65mm ID x 24.90mm OD x 3.20mm, HT Boron, ZNM | BUR |
| 4. | 300389 | [4] | BOLT,M12 x 1.75 x 35mm | NH Superseded by part number: 628-12035 |
| 5. | 9824055 | [1] | HYD CONNECTOR,1-7/16" - 12 ORFS x 1-5/16" - 12 ORB | WIN |
| 6. | 201-339 | [1] | ELBOW,90º, 1 7/16"-12 x 1 7/16"-12 Fem Sw ORFS | CAS |
| 7. | 84256799 | [1] | 90 ELBOW | BUR |
| 8. | 84387418 | [1] | HOSE ASSY.,25.4mm ID x 558mm L, SAE 100R17 | BUR |
| 9. | 84387419 | [1] | HOSE ASSY.,38.1mm ID x 777mm L, SAE 100R4 | BUR |
| 10. | 84180945 | [1] | COLLAR CLAMP,1.87" - 2.18" | CUR Superseded by part number: 86050202 |
| 11. | 47593292 | [1] | SEAL KIT | BURHydrostatic Pump |
| 12. | 9824050 | [2] | O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro | WINFit Hose Callout 8 Superseded by part number: 87473574 |
| 13. | 9840589 | [1] | O-RING,0.07" Thk x 1.489" ID, -29, Cl 6, 90 Duro | WINFits Hose Callout 9 |
