| 1. | 47547253 | [1] | FRAME | BURC Inside Superseded by part number: 47741554 |
| 2. | 84537899 | [2] | PIN,50mm OD x 143.5mm L | BUR |
| 3. | 84537898 | [2] | PIN,50.75mm OD x 156mm L | BUR |
| 4. | 84537897 | [6] | PIVOT PLATE | BURPin Superseded by part number: 47739086 |
| 5. | 84385169 | [12] | BUSHING,52.32mm ID x 57.15mm OD x 15.75mm L | BURSpacer |
| 6. | 87690482 | [4] | WASHER,2.03" ID x 2.75" OD x 0.07" Thk | GI |
| 7. | 906037R1 | [24] | HEX SOC SCREW,FLAT, M10 x 30mm, Cl 10.9 | CAS |
| 8. | 84380507 | [2] | PIN,44.4mm OD x 175mm L | BURWith Cylinder Mount |
| 9. | 84550963 | [1] | EYE,1-3/4" - 12 | BURLeft Hand |
| 10. | 84380519 | [2] | SPACER,16.5mm ID x 25.5mm OD x 12.75mm L | BUR |
| 11. | 896-15016 | [3] | WASHER,17.5mm ID x 34mm OD x 5mm Thk | CAS Superseded by part number: 82848079, 86639326 |
| 12. | 84246776 | [2] | PREV TORQUE BOLT,Hex, M16 x 35mm, Cl 10.9 | BUR |
| 13. | 84541743 | [2] | SHIM,45.5mm ID x 53.5mm OD x 3mm Thk | BURPitch Link |
| 14. | 84385270 | [6] | SHIM,45.5mm ID x 53.5mm OD x 1mm Thk | BURPitch Link |
| 15. | 495-81282 | [9] | WASHER,2 1/16" x 3" x .109" | CAS Superseded by part number: 86625259 |
| 16. | 84538461 | [1] | PIN,50.75mm OD x 256.8mm L | BURDIA Tilt Cylinder Rod |
| 17. | 103-16200 | [8] | SNAP RING,#200, Ext | CAS Superseded by part number: 84158898 |
| 18. | 87546004 | [3] | PIN,50.77mm OD x 200.8mm L | BURDIA Angle and Tilt Cylinder Rod |
| 19. | D95147 | [4] | WIPER SEAL,69.8mm ID x 82.58mm OD x 7.92mm Thk | CAS |
| 20. | 87477364 | [4] | SHIM | BUR |
| 21. | 134167A1 | [4] | SHIM,72mm ID x 140mm OD x 2.05mm Thk | CAS |
| 22. | 47539780 | [2] | PIN | BURC - Frame |
| 23. | 419041A1 | [4] | SPACER | BURMounting |
| 24. | 419223A1 | [4] | WASHER | BURHardened |
| 25. | 627-16050 | [4] | BOLT,Hex, M16 x 2 x 50mm, Cl 10.9, Full Thd | CAS Superseded by part number: 412398 |
| 26. | 84537900 | [2] | PIN,50mm OD x 177.8mm L | BUR |
| 27. | 47361746 | [1] | PIN,82.49mm OD x 271.6mm L | BURBlade |
| 28. | 84538603 | [1] | SPACER,82.8mm ID x 110mm OD x 51.05mm L | BURC - Frame |
| 29. | 84538604 | [1] | SPACER,82.8mm ID x 110mm OD x 23.2mm L | BURC - Frame |
| 30. | 9843611 | [1] | BOLT,Hex, M16 x 2.0 x 55mm, Cl 10.9 | WIN Superseded by part number: 86900235 |
| 31. | 87690483 | [4] | WASHER,2.03" ID x 2.75" OD x 0.12" Thk | GI |
| 32. | 412141 | [1] | NUT,M10 x 1.5, Cl 8 | ZED Superseded by part number: 190003888452 |
| 33. | 84550961 | [1] | TUBE | BUR |
| 34. | 43252 | [1] | BOLT,Hex, M10 x 1.5 x 80mm, Cl 10.9 | GI |
| 35. | 87311755 | [1] | BEARING ASSY,44.45 mm ID x 63.88 mm OD x 38.8239 mm | BURRight Hand |
| 36. | 84550959 | [1] | LINK CONROD | BHBPitch, Incl 9, 13, 14, 32 - 35 |
