纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (48.100.AD [02]) - CHAIN ASSEMBLY New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
558 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87567383 | [45] | BUSHING | BURRotating |
| 2. | 87582715 | [45] | BUSHING,38.45mm ID x 65mm OD x 131.4mm L | BUR |
| 3. | 87582716 | [45] | LARGE PIN | BURTrack |
| 4. | 87582717 | [90] | THRUST RING | BUR |
| 5. | 87582718 | [45] | PLUG | BURRubber Oil |
| 6. | 87582719 | [44] | TRACK LINK | BURLeft Hand |
| 7. | 87582720 | [44] | TRACK LINK | BURRight Hand |
| 8. | 87582724 | [2] | BOLT | BURMaster Link |
| 9. | 87582725 | [2] | BOLT | BURMaster Link |
| 10. | 87582722 | [1] | TRACK LINK | BURMaster Link Left Hand Superseded by part number: 87582786 |
| 11. | 87582721 | [1] | TRACK LINK | BURMaster Link Right Hand Superseded by part number: 87624375 |
| 12. | 87582727 | [90] | SEAL,55mm ID x 63mm OD x 10.7mm Thk | BURTrack Chain |
