纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (48.110.AA[02]) - SUSPENSION - NARROW New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
895 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84557681 | [1] | SHAFT | BURPivot, 76 Gauge |
| 2. | 84537757 | [1] | BEAM | BUREqualizer, LT, Incl 14 - 16 Superseded by part number: 47705794 |
| 3. | 84301353 | [1] | SPECIAL PIN | BURWith Center |
| 4. | T31129 | [2] | BUSHING,19.66mm ID x 31.75mm OD x 17.48mm L | CASLift Link |
| 5. | 87495304 | [2] | FLANGE BOLT,M6 x 55.4mm, Cl 10.9 | BRRFlange, M16 x 40 Full, 10.9 |
| 6. | 84015293 | [1] | ELBOW,90º, 1/8"-27 Female x 1/8"-27 Male | ZED Superseded by part number: 217-20 |
| 7. | 84410662 | [1] | HOSE ASSY.,3.17mm ID x 1274mm L, SAE 100R7 | BURHydraulic, Grease |
| 8. | F53473 | [1] | LOCK NUT,1/8-27 NPSM | CASLube Hose, 1/8-27 Npsm Superseded by part number: 76085536 |
| 9. | 219-8 | [1] | LUBE NIPPLE,1/4"-28 x 1/2" | CAS Superseded by part number: 87414 |
| 10. | 84380964 | [4] | CLAMP | BURLo, Pivot Shaft Superseded by part number: 47548945 |
| 11. | 11062476 | [4] | SNAP RING,M90, Int | TTF Superseded by part number: |
| 12. | 87016610 | [8] | WASHER,25.8mm ID x 44.5mm OD x 5mm Thk | RAC |
| 13. | 87316948 | [8] | BOLT,Hex, M24 x 290mm, Cl 10.9 | LECM24 x 290 x 10.9 Superseded by part number: 827-24290 |
| 14. | 11075676 | [4] | SNAP RING,M115, Int | MKTRegular |
| 15. | 87344647 | [2] | SEALING RING | ZED Superseded by part number: 139059C1 |
| 16. | 87381270 | [2] | SPHERICAL BEARING,60mm ID x 90mm OD x 44mm W | BURRadial Spherical |
