纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (88.100.37[02]) - DIA, REAR, RETREVIAL , HOOK New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
423 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47569423 | [1] | KIT | BURDIA, Rear Retrieval |
| 2. | 47569458 | [1] | INSTRUCTION | BUR |
| 3. | 87564731 | [2] | BOLT,Hex, M24 x 80mm, Cl 10.9 | BUR |
| 4. | 896-11024 | [2] | WASHER,26mm ID x 44mm OD x 5mm Thk | IH Superseded by part number: 87016608 |
| 5. | 47496259 | [1] | CABLE,405mm L | BUR |
| 6. | 47496260 | [2] | SLEEVE | BUR |
| 7. | 47496373 | [1] | HITCH | BUR |
| 8. | 87339515 | [1] | PIN | BUR |
| 9. | A30338 | [1] | PIN | CAS Superseded by part number: 270184 |
