| 1. | 47591333 | [1] | KIT | BURRipper Superseded by part number: 47670640 |
| 2. | 47591925 | [1] | INSTRUCTION | BUR |
| 3. | 614-10040 | [2] | BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8, Full Thd | CAS Superseded by part number: 120112 |
| 4. | 832-10410 | [4] | NUT,M10 x 1.5, Cl 8 | CAS Superseded by part number: 190003888452 |
| 5. | 87352784 | [1] | TUBE,12.70 mm OD | BUR |
| 6. | 87352785 | [1] | TUBE,12.70 mm OD | BUR |
| 7. | 201-112 | [2] | HYD CONNECTOR,13/16"-16 ORFS x 7/8"-14 ORB | CAS Superseded by part number: 73338799 |
| 8. | 201-326 | [2] | ELBOW,90º, 13/16"-16 x 7/8"-14, Adj, ORFS | CAS Superseded by part number: 85802961 |
| 9. | 201-128 | [2] | HYD CONNECTOR,13/16"-16 ORFS x 1 1/16"-12 ORB | CAS |
| 10. | 87311572 | [6] | SPACER,12.7mm x 19mm x 9mm | BUR |
| 11. | 238-6014 | [2] | O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro | CAS Superseded by part number: 9992298 |
| 12. | 47587805 | [2] | HOSE,9.53mm ID x 2300mm L, SAE 100R17 | BUR |
| 13. | 87417721 | [1] | THREADED INSERT,M10 x 1.5-6H x 29 L | BUR |
| 14. | 86637999 | [2] | CLAMP,19mm, Coat, 11.9mm Bolt Hole, P Type | FAR |
| 15. | 87036413 | [1] | SPACER,5/8" Pipe x 15/16" | CAS |
| 16. | 87655046 | [1] | SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk | BUR |
| 17. | 120070 | [1] | BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8 | NH |
| 18. | 47588965 | [1] | PLATE | BUR |
| 19. | 47588982 | [1] | PLATE | BUR |
| 20. | 47588828 | [2] | BRACKET | BUR |
| 21. | 87655042 | [8] | SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk | BUR |
| 22. | 43128 | [2] | BOLT,M8 x 1.25 x 30mm, Cl 8.8 | NH |
| 23. | 16104121 | [4] | NUT,M8 x 1.25, Cl 10 | LEC Superseded by part number: 17152821 |
| 24. | 85802820 | [1] | CHECK VALVE | IMO |
| 25. | 9993143 | [1] | HYD CONNECTOR,11/16" - 16 ORFS x 9/16" - 18 ORB | IMO |
| 26. | 84989392 | [1] | ELBOW,90º, 11/16"-16 ORFS x 11/16"-16 Fem Sw | ZED |
| 27. | 9840543 | [1] | 90 ELBOW,90°, 11/16"-16 x 9/16"-18 Adj, ORFS | WIN |
| 28. | 9992342 | [2] | HYD CONNECTOR | BAS Superseded by part number: E9NN3R862AA |
| 29. | 827-8060 | [2] | BOLT,Hex, M8 x 1.25 x 60mm, Cl 10.9 | CAS Superseded by part number: 86625005 |
| 30. | 120113 | [2] | BOLT,Hex, M10 x 1.5 x 50mm, Cl 8.8, Full Thd | NH |
| 31. | 87698854 | [2] | NUT,M10 | JES |
| 32. | 87655044 | [6] | SPECIAL WASHER,17.75mm ID x 31.50mm OD x 4.20mm, HTS Boron, ZNM | BUR |
| 33. | 412398 | [6] | BOLT,Hex, M16 x 2 x 50mm, Cl 10.9, Full Thd | NH |
| 34. | 405737A2 | [2] | SQUARE NUT | BUR |
| 35. | 336371A1 | [2] | PIN | CAS |
| 36. | 84466221 | [2] | HOSE,12.7mm ID x 760mm L, SAE 100R13 | BUR |
| 37. | 84466222 | [2] | HOSE,12.7mm ID x 770mm L, SAE 100R16 | BUR |
| 38. | 84388248 | [1] | SUPPORT | BHB |
| 39. | 84388253 | [1] | SUPPORT | BHB |
| 40. | 87355606 | [4] | PIN,50.8mm OD x 144.78mm L | BUR |
| 41. | 87355608 | [2] | PIN,38.1mm OD x 144.78mm L | BUR |
| 42. | 896-15016 | [6] | WASHER,17.5mm ID x 34mm OD x 5mm Thk | CAS Superseded by part number: 82848079, 86639326 |
| 43. | 892-11016 | [6] | LOCK WASHER,16.4mm ID x 27.4mm OD x 5mm Thk | CAS Superseded by part number: 87016618 |
| 44. | 896-11024 | [18] | WASHER,26mm ID x 44mm OD x 5mm Thk | IH Superseded by part number: 87016608 |
| 45. | 87564731 | [18] | BOLT,Hex, M24 x 80mm, Cl 10.9 | BUR |
| 46. | 614-16030 | [6] | BOLT,Hex, M16 x 2 x 30mm, Cl 8.8, Full Thd | CAS Superseded by part number: 43167 |
| 47. | 87383797 | [2] | WASHER | BUR |
| 48. | 87383796 | [2] | WASHER | BUR |
| 49. | 47496497 | [1] | KIT | BUR |
| 50. | 495-81282 | [8] | WASHER,2 1/16" x 3" x .109" | CAS Superseded by part number: 86625259 |
| 51. | 87383799 | [4] | PIN,50.8mm OD x 179.8mm L | BUR |
| 52. | 103-16200 | [8] | SNAP RING,#200, Ext | CAS Superseded by part number: 84158898 |
| 53. | 87339515 | [1] | PIN | BUR |
| 54. | A30338 | [1] | PIN | CAS Superseded by part number: 270184 |
| 55. | 87383798 | [3] | PIN,50.8mm OD x 139.7mm L | BUR |
| 56. | 87383800 | [2] | PIN,44.45mm OD x 179.8mm L | BUR |
| 57. | 495-81226 | [4] | WASHER,46.02mm ID x 63.5mm OD x 3.35mm Thk | CAS Superseded by part number: 87613252 |
| 58. | 103-16175 | [4] | SNAP RING,#175, Ext | CAS Superseded by part number: 86625149 |
| 59. | 419223A1 | [3] | WASHER | BUR |
| 60. | 492-11062 | [3] | BEARING WASHER,5/8" | CAS Superseded by part number: 86729275 |
| 61. | 409-91020 | [3] | BOLT | BUR |
| 62. | 84428520 | [1] | MOUNT | BUR |
| 63. | 84322203 | [1] | CLIP | BUR |
| 64. | 895-11006 | [2] | WASHER,M6 x 12mm OD x 1.6mm | CAS Superseded by part number: 86588450 |
| 65. | 614-6020 | [2] | BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd | CAS Superseded by part number: 120100 |
| 66. | 84399654 | [1] | JOYSTICK | BUR |
| 67. | 13311217 | [4] | SCREW,Pozidriv Oval Hd, Csk, M5 x 20mm, Cl 5.8, Full Thd | IMO |
| 68. | 47496259 | [1] | CABLE,405mm L | BUR |
| 69. | 47496260 | [2] | SLEEVE | BUR |
| 70. | 84431325 | [2] | TEE,13/16"-16 ORFS x 13/16"-16 Fem Sw Br | ZED |
| 71. | 434130A1 | [8] | HOSE CLAMP | BUR |
