凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (35.550.04) - BALE TENSION HYDRAULIC CYLINDER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
521 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84246781
|
[2] |
HYDRAULIC CYLINDER,Double Acting, 25.4mm Rod, 686mm Stroke
|
NH
Bale Tension
|
| 2. |
84314054
|
[1] |
CYLINDER HEAD
|
NH
Superseded by part number: 47584867
|
| 3. |
84313737
|
[1] |
PISTON
|
NH
|
| 4. |
84313736
|
[1] |
PISTON ROD/GLAND
|
NH
Superseded by part number: 47584854
|
| 5. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Tube
|
| 7. |
84313742
|
[1] |
SEAL KIT
|
NH
|
| 8. |
87629
|
[1] |
NUT,5/8"-11, GB
|
GI
Superseded by part number: 9602227
|
| 9. |
280864
|
[1] |
BOLT,Hex, 7/8" - 9 x 3 3/4", Gr 5
|
GI
|
