纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (88.100.55[06]) - DIA, ROPS , LIGHT FIED KIT (W/O SWEEPS) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
530 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47415385 | [1] | KIT | BURROPS Lighting without Sweeps |
| 2. | 47415381 | [1] | INSTRUCTION | BUR |
| 3. | 87693641 | [1] | BRACKET | BUR |
| 4. | 844-10035 | [1] | BOLT,Hex, M10 x 35mm, Cl 8.8 | CAS Superseded by part number: 86511845 |
| 5. | 87555142 | [3] | LIGHT ASSY.,Halogen, 24V, 65W, Clear | BUR |
| 6. | 87655046 | [3] | SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk | BUR |
| 7. | 614-10016 | [3] | BOLT,Hex, M10 x 1.5 x 16mm, Cl 8.8, Full Thd | CAS Superseded by part number: 300383 |
| 8. | L18331 | [3] | CABLE TIE,375.9mm L | CAS Superseded by part number: 529070 |
