纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (90.100.AU[02]) - FRONT COVER, HOOD New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
684 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84589150 | [1] | SUPPORT | BUR |
| 2. | 84495476 | [1] | HINGE | BUR |
| 3. | 86992672 | [1] | EMBLEM | RAC |
| 4. | 84494359 | [1] | PLATE | BUR |
| 5. | 86625060 | [2] | PUSH-ON NUT,Self, Threading, 1/4" | JES |
| 6. | 87655043 | [8] | WASHER,M12, 13.65mm ID x 24.90mm OD x 3.20mm, HT Boron, ZNM | BUR |
| 7. | 398792 | [2] | SCREW,Hex, M12 x 25mm, Cl 10.9 | WIN |
| 8. | 337563 | [3] | SCREW,M12 x 1.75 x 47.68mm, Cl 10.9 | NH |
| 9. | 43260 | [3] | BOLT,Hex, M12 x 1.75 x 30mm, Cl 10.9, Full Thd | BHB |
| 10. | 47416490 | [1] | GRILLE | BUR |
