凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (55.435.02) - NET ACTUATOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
642 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86634125
|
[1] |
ELECTRIC MOTOR
|
NH
Net Acttuator
|
| 1. |
86634125R
|
[1] |
REMAN-ELECTRIC ACTUATOR
|
NH
Reman for New PN 86634125
|
| 1. |
86634125C
|
[1] |
CORE-ELECTRIC ACTUATOR
|
NH
Return Number
|
| 2. |
84318531
|
[1] |
ARM
|
NH
Net & Twine Potentiometer
|
| 3. |
84368388
|
[1] |
BRACKET, SUPPORTING
|
NH
Superseded by part number: 84601250
|
| 4. |
9672521
|
[2] |
LOCK WASHER,Ext Tooth, #10
|
WIN
|
| 5. |
86977396
|
[1] |
POTENTIOMETER,3000 Ohm, 16 VDC
|
PA
|
| 6. |
84308004
|
[1] |
HUB
|
NH
|
| 7. |
86000439
|
[1] |
SNAP RING,0.288" ID x 0.66" OD x 0.037" Thk, External
|
NH
|
| 8. |
9804277
|
[1] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 9. |
412255
|
[2] |
BOLT,Hex, M4 x 20mm, Cl 8.8
|
NH
|
| 10. |
120104
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 11. |
86613601
|
[1] |
WASHER,14.88mm ID x 28.69mm OD x 7.35mm Thk
|
NH
Urethane
|
