凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (55.628.01) - NET WRAP SENSOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
251 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84275950
|
[1] |
MOUNT
|
NH
|
| 2. |
84319036
|
[1] |
ARM
|
NH
|
| 3. |
84308004
|
[1] |
HUB
|
NH
|
| 4. |
84294382
|
[1] |
STRAP
|
NH
|
| 5. |
0C
|
[2] |
ORDER COMPONENTS
|
NH
Sensor
|
| 6. |
86637389
|
[2] |
SPRING
|
NH
|
| 7. |
86977396
|
[1] |
POTENTIOMETER,3000 Ohm, 16 VDC
|
PA
|
| 8. |
86000439
|
[1] |
SNAP RING,0.288" ID x 0.66" OD x 0.037" Thk, External
|
NH
|
| 9. |
80756
|
[1] |
COTTER PIN,1/8" x 3/4"
|
NH
|
| 10. |
177822
|
[1] |
SPACER,8.33mm ID x 12.7mm OD x 4.32mm Thk
|
NH
|
| 11. |
9804258
|
[5] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 12. |
86507486
|
[12] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 13. |
412255
|
[2] |
BOLT,Hex, M4 x 20mm, Cl 8.8
|
NH
|
| 14. |
86613601
|
[1] |
WASHER,14.88mm ID x 28.69mm OD x 7.35mm Thk
|
NH
Urethane
|
| 15. |
80702
|
[2] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 16. |
80664
|
[1] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 17. |
9672521
|
[2] |
LOCK WASHER,Ext Tooth, #10
|
WIN
|
| 18. |
86610200
|
[2] |
THREADED INSERT,M8 x 1.25
|
NH
|
| 19. |
86610201
|
[2] |
INSERT,M8
|
NH
|
| 20. |
9804277
|
[13] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
