凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (60.220.02[02]) - WINDGUARD SUPPORT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
484 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84315673
|
[1] |
SUPPORT
|
NH
RH Superseded by part number: 84355996
|
| 2. |
43130
|
[1] |
BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8
|
NH
|
| 3. |
84300966
|
[1] |
SUPPORT
|
NH
LH Superseded by part number: 84355659
|
| 4. |
87017553
|
[1] |
ANGLE
|
PA
LH
|
| 5. |
86629542
|
[1] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 6. |
9804261
|
[3] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 7. |
9804278
|
[5] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 8. |
86620024
|
[5] |
WASHER,10.3mm ID x 25.4mm OD x 5.2mm Thk
|
NH
|
| 9. |
87355307
|
[4] |
LOCK
|
PA
Cam
|
| 10. |
9804264
|
[2] |
FLANGE BOLT,M10 x 50mm, 26mm Thd, Cl 8.8
|
NH
Superseded by part number: 16587625
|
| 11. |
29524
|
[2] |
SPRING
|
PA
Superseded by part number: 86635755
|
| 12. |
87362
|
[1] |
WASHER,5/16" SAE
|
NH
Superseded by part number: 83918746
|
