凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (60.220.03) - PICKUP REEL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
323 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84206395
|
[1] |
REEL TINE
|
NH
|
| 2. |
84226032
|
[4] |
TINE BAR
|
NH
|
| 3. |
87607074
|
[36] |
TINE
|
NH
Economy, Standard
|
| 3. |
87394242
|
[36] |
TORSION SPRING,Coiled, 2 Prong, 186.5mm L
|
NH
Premium, Optional
|
| 4. |
84350126
|
[4] |
CAM FOLLOWER,1/2" - 20 x 38mm OD x 54.5mm L
|
NH
|
| 5. |
86641856
|
[4] |
BEARING,27.1 mm ID x 47 mm OD x 25.4 mm
|
PA
Superseded by part number: 54770
|
| 6. |
638025
|
[4] |
FLANGE
|
NH
|
| 7. |
54695
|
[4] |
BEARING HOUSING
|
NH
|
| 8. |
87713401
|
[36] |
SPACER
|
NH
Tooth Superseded by part number: 84427925
|
| 9. |
84237357
|
[36] |
SPECIAL BOLT
|
NH
|
| 10. |
9849938
|
[16] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 7/8", Gr 5, Full Thd
|
NH
|
| 11. |
120090
|
[4] |
BOLT,Hex, M16 x 50mm, Cl 8.8
|
NH
|
| 12. |
703960
|
[8] |
WASHER
|
NH
Superseded by part number: 87642988
|
| 13. |
87642936
|
[4] |
WASHER,16.8mm ID x 27.7mm OD x 1.7mm Thk
|
NH
|
| 14. |
140045
|
[8] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 15. |
87032200
|
[1] |
CAM
|
PA
LH Outer Superseded by part number: 87641735
|
| 16. |
140020
|
[4] |
WASHER,17.5mm ID x 30mm OD x 3mm Thk
|
NH
|
| 17. |
86629544
|
[36] |
NUT,5/16” – 18, GR B
|
NH
Superseded by part number: 280736
|
| 18. |
86521609
|
[8] |
FLANGE NUT,Flg, 3/8"-16
|
NH
|
| 19. |
247780
|
[8] |
SERRATED NUT,Flg, USR, 3/8"-16
|
GI
|
| 20. |
88130
|
[4] |
NUT,1/2"-20, GC
|
NH
|
| 21. |
9804280
|
[4] |
FLANGE NUT,Hex, M16, Cl 8
|
NH
Superseded by part number: 86512498
|
| 22. |
136521
|
[4] |
COTTER PIN,5.7mm OD x 44.45mm L
|
NH
|
| 23. |
87032003
|
[1] |
CAM
|
PA
LH Inner
|
