凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (60.220.08) - PICKUP GAUGE WHEEL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
589 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84361378
|
[1] |
WHEEL ASSY
|
NH
Pickup Gauge
|
| 2. |
87578241
|
[2] |
BUSHING,19.56mm ID x 38.1mm OD x 15.88mm L
|
PA
|
| 3. |
84499069
|
[1] |
WHEEL,203.2mm OD x 57.4mm W
|
NH
|
| 4. |
84499071
|
[1] |
TIRE TUBE
|
NH
410/350-6
|
| 5. |
84499073
|
[1] |
TYRE/TIRE
|
NH
410/350-6
|
| 6. |
84499074
|
[1] |
NEEDLE BEARING
|
NH
|
| 7. |
87569
|
[1] |
LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive
|
PA
|
