| 1. |
84133540
|
[1] |
CHANNEL
|
NH
|
| 2. |
84133519
|
[1] |
SHAFT
|
NH
|
| 3. |
84133515
|
[1] |
DISC
|
NH
|
| 4. |
84133521
|
[1] |
NOTCHED DISK
|
NH
|
| 5. |
84133522
|
[1] |
DOG
|
NH
|
| 6. |
84133523
|
[1] |
HUB
|
NH
|
| 7. |
84133535
|
[1] |
SHAFT
|
NH
|
| 8. |
33781
|
[1] |
KNOB
|
NH
|
| 9. |
18
|
[1] |
SPRING
|
NH
|
| 10. |
84133532
|
[1] |
LOCK PIN
|
NH
|
| 11. |
84133538
|
[1] |
FLEXIBLE CABLE
|
NH
|
| 12. |
84238738
|
[1] |
SPACER,10.34mm ID x 15.88mm OD x 12mm L
|
NH
|
| 13. |
86511845
|
[1] |
BOLT,M10 x 44.2mm OAL, Cl 8.8, Full Thd
|
GI
|
| 14. |
84133539
|
[1] |
STOP
|
NH
|
| 15. |
87015931
|
[1] |
BOLT,Hvy Hex, M6 x 35mm, Cl 8.8
|
RAC
|
| 16. |
86619800
|
[1] |
FLANGE NUT,M6 x 1, Cl 8
|
RAC
|
| 17. |
43465
|
[1] |
CARRIAGE BOLT,Short NK, M8 x 30, Cl8.8, Full Thd
|
NH
Superseded by part number: 811-8030
|
| 18. |
86619801
|
[1] |
FLANGE NUT,M8 x 1.25, Cl 8
|
PA
Superseded by part number: 87681210
|
| 19. |
9804277
|
[3] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 20. |
80708
|
[1] |
COTTER PIN,1/8" x 1 1/2"
|
NH
|
| 21. |
26402
|
[1] |
WASHER,25.8mm ID x 38.1mm OD x 1.7mm Thk
|
NH
|
| 22. |
9804276
|
[2] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 23. |
86977786
|
[1] |
BOLT,Hex, M6 x 1 x 25mm, Cl 8.8
|
GI
|
| 24. |
86619802
|
[1] |
FLANGE NUT,M10 x 1.5, Cl 8
|
PA
Superseded by part number: 87547587
|
| 25. |
308761
|
[2] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 26. |
9804258
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
