神钢零件查询(6D22-T) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (05-005) - EMERGENCY PARTS 090-500B Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
386 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA3089804100 | [1] | SOLENOID | KOBSOLENOID, STOP 24V ND |
| 2. | VAMF140221 | [4] | BOLT | KOBBOLT, FLANGE 8X12 |
| 3. | VA0303320650 | [1] | ROD L=650, M0 ONLY | |
| . . | VA0303320250 | [1] | ROD L=250, M6 ONLY | |
| . . | VAME050929 | [1] | CONNECTING ROD | KOBROD, MY ONLY Superseded by part number: VAME157135 |
| 4. | VAMC010080 | [2] | BALL JOINT | KOBJOINT, BALL, M0 & M6 ONLY Superseded by part number: 240384A1 |
| 4A. | VAMC429036 | [2] | CLEVIS | KOBCLEVIS, M7 ONLY |
| 5. | VAMF430724 | [2] | NUT 6 | |
| 6. | VAMF472953 | [2] | PIN | KOBPIN, CLEVIS 6X16, M7 ONLY |
| 7. | VAMF472024 | [2] | PIN, SPLIT, 1.6X15, M7 ONLY | |
| . . | VAMF450004 | [2] | WASHER | KOBWASHER, PLAIN 6, M7 ONLY |
| 8. | VAMF445003 | [2] | NUT, SELF LOCK 6, M0 & M6 ONLY | |
| 15. | VAME059906 | [1] | BRACKET, SOLENOID, M0 ONLY | |
| . . | VAME050948 | [1] | M6 ONLY | |
| . . | VAME059949 | [1] | M7 ONLY | |
| 16. | VAMH000706 | [2] | SCREW | KOBBOLT, FLANGE 10X16, M0 & M6 ONLY Superseded by part number: 132289A1 |
| 17. | VAMH000737 | [1] | BOLT | KOBBOLT, FLANGE 18X90, M0 ONLY |
| . . | VAMF140223 | [2] | BOLT | KOBBOLT, FLANGE 8X16, M6 ONLY |
| 18. | VAMH005027 | [1] | WASHER | KOBWASHER, M0 ONLY |
