纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (90.151.AN[01]) - CAB CONSOLE, RIGHT HAND New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
286 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84187829 | [4] | SCREW,Torx Pan Hd, M5 x 25mm, Cl 4.8 | BASM5 X 25 Full Torx 4.8 |
| 2. | 47548725 | [1] | FOAM INSULATION | BURRight Hand Console |
| 3. | 47527154 | [1] | PAD | BURRight Hand Console |
| 4. | A161780 | [2] | BUMPER | CASRubber Rear Hood |
| 5. | 87475892 | [4] | CUP WASHER | BURNylon |
| 6. | 87341593 | [4] | SCREW,Oval Hd, Csk, M6 x 20mm, Cl 4.8 | BURM6 X 20 Oval Countersunk |
