纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (90.156.AK[01]) - CAB GLASS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
733 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 829-1412 | [2] | NUT,M12, Cl 10 | CAS Superseded by part number: 337475 |
| 2. | 845-6010 | [8] | BOLT,Hvy Hex, M6 x 10mm, Cl 8.8 | CAS |
| 3. | 857-8025 | [4] | BOLT,Hvy Hex, M8 x 25mm, Cl 10.9 | CAS |
| 4. | 892-11006 | [8] | LOCK WASHER,M6 | CAS Superseded by part number: 86517328 |
| 5. | 895-15012 | [2] | WASHER,M12 x 28 x 2.5 | IH Superseded by part number: 86625254 |
| 6. | 20344 | [2] | LOCK PIN,3/16" x 1/2", Slotted | MKT Superseded by part number: 88626 |
| 7. | 280112 | [2] | BOLT,Hex, 1/4" - 20 x 1-1/2", Gr 5 | NH |
| 8. | 84149751 | [1] | LATCH | BUR |
| 9. | 84150074 | [1] | LATCH | BUR |
| 10. | 84207116 | [2] | SEAL | BUR |
| 11. | 84407369 | [1] | COVER | BUR |
| 12. | 84407368 | [1] | COVER | BUR |
| 13. | 84381320 | [4] | PIN,10mm OD x 135mm L | BUR |
| 14. | 86637933 | [2] | JAM NUT,5/16" - 24, G5 | FAR |
| 15. | 87330642 | [2] | BUMPER | BUR |
| 16. | 87342605 | [8] | BOLT | BN |
| 17. | 84405934 | [2] | BOLT,12mm OD x 52.3mm L | BUR |
| 18. | 87656137 | [4] | BOLT,M8 x 28.1mm, Cl 10.9 | FAR |
| 19. | 87661394 | [2] | LOCKING HANDLE | WIC |
| 20. | 84405935 | [2] | GUARD | BUR |
| 21. | 391845A1 | [8] | WASHER,11.1mm ID x 25.4mm OD x 1.6mm Thk | CAS |
| 22. | 442773A1 | [8] | CIRCLIP | CAS Superseded by part number: 800-438 |
| 23. | 825-2406 | [2] | FLANGE NUT,M6 x 1, Flg, Cl 8 | CAS Superseded by part number: 9804276 |
| 24. | 840-1620 | [2] | SCREW,Pan, M6 x 20mm, Cl 4.8 | CAS Superseded by part number: 86511830 |
| 25. | 895-25006 | [2] | WASHER,M6 x 18 x 1.6 | CAS Superseded by part number: 86624182 |
| 26. | 87397399 | [1] | LATCH | BUR |
| 27. | 87397400 | [2] | HINGE | BUR |
| 28. | 87517925 | [2] | WASHER | BUR |
| 29. | 87517926 | [2] | BUSHING | BUR |
| 30. | 87615099 | [4] | WASHER | BUR |
| 31. | 87721465 | [1] | GLASS,CAB | BUR |
| 32. | 87721466 | [1] | GLASS,CAB | BUR |
