| 1. |
9842286
|
[3] |
ROLLER
|
NH
Tailgate Idler, Incl 14, Serial Range: -YCN172444 Superseded by part number: 84600572
|
| 1. |
84600572
|
[3] |
ROLL
|
PLO
Tailgate Idler, Incl 14, Start Serial: YDN179981
|
| 1. |
84562588
|
[1] |
ROLL
|
NH
Tailgate Idler, Rubber Guide, Incl 14, Serial Range: YCN172445-YDN179980
|
| 1. |
47522795
|
[1] |
ROLL
|
NH
Tailgate Idler, Rubber Guide, Incl 14, Start Serial: YDN179981
|
| 2. |
9849616
|
[1] |
ROLL
|
NH
Tailgate Nose, Incl 15
|
| 3. |
9823371
|
[3] |
SHAFT
|
NH
Superseded by part number: 87023402
|
| 4. |
86521602
|
[4] |
SUPPORT
|
NH
Superseded by part number: 87023400
|
| 5. |
86516321
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87654791
|
| 6. |
9608116
|
[2] |
SUPPORT
|
PA
Superseded by part number: 89608116, 86635251
|
| 7. |
84255597
|
[1] |
ANGLE
|
NH
|
| 8. |
9824642
|
[6] |
BOLT,M12 x 1.75 x 42.68mm, Cl 10.9
|
BHB
Superseded by part number: 626-12035
|
| 9. |
9804278
|
[4] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 10. |
86512446
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 11. |
9706702
|
[2] |
BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8
|
NH
|
| 12. |
65319
|
[8] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 13. |
29684
|
[8] |
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
|
NH
|
| 14. |
9845576
|
[12] |
BALL BEARING,38.1mm ID x 80mm OD x 22mm W
|
NH
, Serial Range: -YDN179980 Superseded by part number: 84330072
|
| 14. |
84259867
|
[12] |
BALL BEARING,38.1mm ID x 80mm OD x 22mm W
|
PLO
, Start Serial: YDN179981
|
| 15. |
353125
|
[2] |
BALL BEARING,45mm ID x 85mm OD x 19mm W
|
NH
|
