凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (62.150.01) - MAIN DRIVE, RH Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
573 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84133377
|
[1] |
SPROCKET
|
NH
25T & 28T RC 60
|
| 2. |
84133372
|
[1] |
SPROCKET
|
NH
28T RC 60
|
| 3. |
84133378
|
[1] |
SPROCKET
|
NH
18T RC 60
|
| 4. |
84133381
|
[1] |
CHAIN
|
NH
45 Pitches, Includes: Ref. 7 & 15
|
| 5. |
86621149
|
[1] |
CHAIN,60, 57 Links x 19.05mm = 1085.85mm
|
NH
57 Pitches, Includes: Ref. 7 & 15
|
| 6. |
86514717
|
[2] |
IDLER WHEEL
|
NH
|
| 7. |
84134453
|
[2] |
OFFSET LINK
|
NH
|
| 8. |
338263
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 70mm, Cl 8.8
|
ZED
|
| 9. |
86511845
|
[2] |
BOLT,M10 x 44.2mm OAL, Cl 8.8, Full Thd
|
GI
|
| 10. |
29684
|
[4] |
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
|
NH
|
| 11. |
58821
|
[2] |
WASHER,45.24mm ID x 56.36mm OD x 1.65mm Thk
|
NH
|
| 12. |
87056525
|
[2] |
WASHER
|
PA
|
| 13. |
604201
|
[8/AR] |
WASHER
|
BEL
Superseded by part number: 86636633
|
| 14. |
86624647
|
[1] |
WASHER,10.8mm ID x 57mm OD x 6.1mm Thk
|
NH
|
| 15. |
84134452
|
[2] |
CONNECTING LINK,RC60, 3/4" Pitch
|
NH
|
| 16. |
694478
|
[1] |
WASHER,13.5mm ID x 57.15mm OD x 4.8mm Thk
|
NH
|
| 17. |
9706685
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 18. |
87123
|
[1] |
WOODRUFF KEY,#28, 5/16" x 2 1/8"
|
GI
|
| 19. |
170055
|
[1] |
KEY
|
ZED
Superseded by part number: 80170055
|
| 20. |
84024216
|
[1] |
LOCK PIN,5mm OD x 50mm L, Slotted
|
PLO
|
| 21. |
412689
|
[1] |
LOCK PIN,8mm OD x 50mm L, Slotted
|
NH
|
| 22. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
