| 1. |
84345406
|
[1] |
ROLL
|
NH
Drive
|
| 2. |
84210314
|
[1] |
ROLLER
|
NH
Floor
|
| 3. |
84255586
|
[1] |
ROLLER
|
NH
Starter
|
| 4. |
87392560
|
[1] |
ROLL
|
NH
Stationary Superseded by part number: 87660302
|
| 5. |
9842286
|
[1] |
ROLLER
|
NH
Back Wrap, Includes: Ref. 36 Superseded by part number: 84600572
|
| 6. |
86516311
|
[1] |
SUPPORT
|
NH
|
| 7. |
86521602
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87023400
|
| 8. |
87602845
|
[2] |
SHIELD
|
PA
|
| 9. |
84255602
|
[2] |
MOUNT
|
NH
Pickup
|
| 10. |
86506990
|
[2] |
HALF-DISC
|
PA
Superseded by part number: 86637198
|
| 11. |
84353131
|
[4] |
FLANGE
|
NH
|
| 12. |
86837676
|
[4] |
FLANGED BEARING
|
PA
Superseded by part number: 86979948
|
| 13. |
9823371
|
[1] |
SHAFT
|
NH
Superseded by part number: 87023402
|
| 14. |
84209364
|
[1] |
ROLLER SHAFT
|
NH
|
| 15. |
84133326
|
[2] |
RING
|
NH
|
| 16. |
52444
|
[4] |
COLLAR,38.2mm ID x 60.33mm OD x 18.3mm Thk
|
NH
Superseded by part number: 47577185
|
| 17. |
86622263
|
[2] |
HUB
|
NH
Superseded by part number: 87660304
|
| 18. |
87398962
|
[1] |
HUB,12.5mm ID x 47.42mm OD x 13.2mm L
|
PA
|
| 19. |
86609558
|
[1] |
BEARING ASSY,45mm ID
|
NH
|
| 20. |
86620027
|
[4] |
FLANGED BEARING,80.02mm ID x 147.6mm OD x 4mm Thk
|
NH
|
| 21. |
52443
|
[4] |
BALL BEARING,38.1mm ID x 79.99mm OD x 22mm W
|
NH
Superseded by part number: 664073R92
|
| 22. |
286909
|
[2] |
BALL BEARING,38.11mm Hex x 84.99mm OD x 30mm W
|
NH
Superseded by part number: 47577178
|
| 23. |
9804268
|
[1] |
BOLT,Hex, M12 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 24. |
43260
|
[2] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 10.9, Full Thd
|
BHB
|
| 25. |
86050286
|
[8] |
FLANGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 26. |
9670066
|
[24] |
FLANGE BOLT,Hex, M12 x 30mm, Cl 8.8
|
NH
|
| 27. |
29684
|
[2] |
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
|
NH
|
| 28. |
58821
|
[2] |
WASHER,45.24mm ID x 56.36mm OD x 1.65mm Thk
|
NH
|
| 29. |
65319
|
[2] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 30. |
86619043
|
[2] |
WASHER,45.2mm ID x 60.3mm OD x 3.68mm Thk
|
NH
|
| 31. |
86636633
|
[1] |
WASHER,42.86mm ID x 57.15mm OD x 1.52mm Thk
|
NH
|
| 32. |
86626959
|
[2] |
WARNING DECAL
|
NH
Shield Open
|
| 33. |
84289539
|
[1] |
FRAME
|
NH
Includes: Ref. 32
|
| 34. |
9804279
|
[10] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 35. |
56513
|
[1] |
PLUG,Hex Soc, 1/8" - 27 NPT
|
NH
Superseded by part number: 86637724
|
