| 1. |
84255867
|
[1] |
MOUNTING PLATE
|
NH
|
| 2. |
84236845
|
[1] |
SUPPORT
|
NH
|
| 3. |
84370406
|
[1] |
WARNING DECAL
|
PA
|
| 4. |
84300955
|
[1] |
SUPPORT
|
NH
RH, Includes: Ref. 3
|
| 5. |
84255884
|
[1] |
LINK
|
NH
|
| 6. |
86617811
|
[1] |
PLATE
|
NH
|
| 7. |
87052763
|
[1] |
GUIDE
|
PA
|
| 8. |
87010284
|
[1] |
CAMSHAFT BEARING
|
NH
|
| 9. |
66006
|
[1] |
BALL BEARING,15.88mm ID x 40mm OD x 12mm W
|
NH
|
| 10. |
86619764
|
[1] |
SPACER
|
NH
|
| 11. |
86572215
|
[1] |
SPRING,Extension, 25.58mm OD x 240.18mm L
|
NH
|
| 12. |
631201
|
[1] |
EYEBOLT
|
NH
|
| 13. |
87675529
|
[1] |
PIN,12.5mm OD x 69.85mm L
|
BRR
|
| 14. |
86619060
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
|
| 15. |
9804263
|
[1] |
BOLT,M10 x 49.2mm, Cl 8.8
|
NH
|
| 16. |
9804264
|
[4] |
FLANGE BOLT,M10 x 50mm, 26mm Thd, Cl 8.8
|
NH
Superseded by part number: 16587625
|
| 17. |
86631064
|
[2] |
WASHER
|
NH
|
| 18. |
87365
|
[2] |
WASHER,0.66" ID x 1.31" OD x 0.1" Thk
|
NH
|
| 19. |
136443
|
[1] |
WASHER,10.32mm ID x 57.15mm OD x 4.8mm Thk
|
NH
|
| 20. |
9804276
|
[3] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 21. |
9804277
|
[4] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 22. |
9804278
|
[5] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 23. |
9628503
|
[2] |
NUT,3/8"-16, G5
|
NH
|
| 24. |
80702
|
[2] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 25. |
80855
|
[1] |
NUT,Hex, 3/8" - 24
|
WIN
|
| 26. |
80722
|
[1] |
LUBE NIPPLE,3/16" x .55" lg, Drive
|
WIN
|
| 27. |
9706717
|
[1] |
BOLT,Hex, M12 x 1.75 x 70mm, Cl 8.8
|
NH
|
| 28. |
9804279
|
[2] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 29. |
9804258
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 30. |
87547587
|
[1] |
LOCK NUT,Hex, M10 x 1.5, Cl 10
|
GI
|
| 31. |
270964
|
[1] |
COTTER PIN,3/8" x 1.62" x .094", Int Hair
|
WIN
|
| 32. |
65319
|
[1] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 33. |
84370400
|
[1] |
DEFLECTOR
|
NH
RH
|
| 34. |
84370399
|
[1] |
DEFLECTOR
|
NH
LH
|
| 35. |
86610200
|
[4] |
THREADED INSERT,M8 x 1.25
|
NH
M8
|
