| 1. |
84273504
|
[1] |
FRAME
|
NH
|
| 2. |
9670066
|
[2] |
FLANGE BOLT,Hex, M12 x 30mm, Cl 8.8
|
NH
|
| 3. |
86622388
|
[1] |
ARM
|
NH
|
| 4. |
86517336
|
[4] |
SUPPORT
|
NH
Superseded by part number: 87643130
|
| 5. |
86614003
|
[2] |
ROLLER
|
NH
Superseded by part number: 87397766
|
| 6. |
86622552
|
[4] |
SHIELD
|
PA
|
| 7. |
65957
|
[1] |
BUSHING,18.23mm ID x 28.61mm OD x 15.75mm W
|
NH
Superseded by part number: 87642987
|
| 8. |
255189
|
[1] |
SPACER
|
NH
Superseded by part number: 87643020
|
| 9. |
280760
|
[4] |
HEX SOC SCREW,FLAT, 3/8" - 16 x 1-1/2"
|
NH
|
| 10. |
86512446
|
[5] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 12. |
9671487
|
[1] |
BOLT,Hex, M12 x 50mm, Cl 8.8
|
PA
|
| 13. |
84269561
|
[1] |
BAFFLE
|
NH
|
| 14. |
794034
|
[2] |
WASHER,20.96mm ID x 28.7mm OD x 1.7mm Thk
|
NH
|
| 15. |
87577038
|
[5] |
RUBBER WASHER,10.5mm ID x 20mm OD x 6.35mm Thk
|
NH
|
| 16. |
86628019
|
[1] |
KNIFE ASSY
|
NH
|
| 17. |
87052763
|
[1] |
GUIDE
|
PA
Comb
|
| 18. |
86593724
|
[2] |
KNIFE,445.8mm L x 38.1mm W x 3.4mm Thk
|
PA
Superseded by part number: 87013989
|
| 19. |
9806864
|
[1] |
KNIFE,382mm L x 38.1mm W x 3.4mm Thk
|
NH
|
| 20. |
412141
|
[5] |
NUT,M10 x 1.5, Cl 8
|
ZED
Superseded by part number: 190003888452
|
| 21. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
|
| 22. |
NH291525
|
[1] |
EDGE
|
NH
Trim Superseded by part number: 86516805
|
| 23. |
9804255
|
[7] |
BOLT,Hex, M6 x 1 x 16mm, Full Thd, Cl 8.8
|
NH
|
| 24. |
412189
|
[1] |
CARRIAGE BOLT,Short Sq Nk, M10 x 1.5 x 80mm, Cl 8.8
|
GI
|
| 25. |
87675529
|
[2] |
PIN,12.5mm OD x 69.85mm L
|
BRR
|
| 26. |
270964
|
[2] |
COTTER PIN,3/8" x 1.62" x .094", Int Hair
|
WIN
|
| 27. |
140046
|
[3] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
